XCM G 1300mm cold milling machine XM1305K with low price

Share on (1600919335800):


Price:$79,000.00

Quantity:


Product Overview

Description



buying guide








Product Description





XM1305K road cold planer is one of the main asphalt concrete road maintenance equipment, mainly used for large-scale highways, urban roads, airports, freight yard, etc for renovation of asphalt pavement. One-time removal of entire concrete overlay.





The equipment features advanced performance, high efficiency, simple process, easy control of milling depth, flexible operation, good maneuverability and the old material recycling and utilization. It is an ideal equipment for pavement maintenance and renovation.





Performance and characteristic:





1.Hydraulic driving milling drum has the obvious characteristics of stable milling and high efficiency.





2.Compact three-wheeled machine with front-wheel drive .





3.The high-strength and high wear resistance imported cutter head and cutter rest have long service life and low construction cost.





4.The imported hydraulic elements have high working reliability.





5.Excellent welting milling performance with right rear leg .





6.Hydraulic handheld breakers and rumble strip equipment can be selected.



























































































































































Milling drumMilling width1300mm
Milling depth300mm
Cutter space18mm
Cutter quality100
Diameter of rotor with cutter980mm
EngineManufacturer
TypeSC9DK260G3
Cooling modeWater-cooled
Number of cylinders6
Rated power/2200rpm192kW
Displacement8.8L
Rated power48L
Comprehensive fuel consumption19.5L
Emission standardCN-4
Electrical system24V
Capacities of tanksFuel tank480L
Hydraulic oil tank120L
Hydraulic tank1600L
Driving performanceOperating speed0-30m/min
Drive speed0-5km/h
Theoretial gradesbility80%
Ground clearance of milling drum300mm
TiresFront crawler dimension1330x260x550mm
Rear crawler dimension1330x260x550mm
Conveyor belt width600mm
Conveyance of milled materialGathering belt width600mm
Theoretical conveying capacity176m³/h
Transport dimensionsConveying belt swing angle±60°
Feeding height5000mm
Machine weightsShipping dimensions of main machine(LxWxH)9950mmx2180mmx3000mm
Unladen weight without filling medium20000kg
Operating mass21500kg




Packaging & Shipping


packing lifting


We supervise the process from the factory to the port designated by the customer to ensure that the customer's products arrive at the destination accurately and safely.





Company Information


lifting factorycertificate


Our factories have passed the certification of relevant organizations.


For example, ISO, CNAS, IAF and so on.


Products have also passed CE, GHOST certification and so on.


exhibition


Every year, we regularly attend the Canton Fair, the Philippines, Indonesia, Russia and other construction machinery and building machinery exhibitions.


customer


We have received more than 1000 clients and training engineers from more than 100 countries around the world.





Our Services





service


 we are famous building machinery manufacturer, professional construction machinery exporter and one stop solution supplier in China, our team have  more than 15 years experience in this field already.


(1)Warranty:Every product issued shall enjoy a one-year/2000 working hour warranty period, during which we will repair or replace the defective parts free of charge if material or process defects occur and spare parts are in normal working condition.


(2)Spare parts:CANMAX is dedicated to provide our clients with genuine spare parts with the highest quality,exact fitness and appropriate function.with our global distributor network,you are guaranteed with fast deliveries and services, wherever you are,please submit your spare parts request to us,and list products name ,description of required parts.we guarantee that your request will be handled quickly and appropriately.


(3)Installation & Maintenance:CANMAX is able to provide with the overall installation of complicated machinery,allowing you to start the normal operation of construction machinery solutions.After installation,we will make inspection of the whole machine,operate equipment,and provide you with testing data reports of installation and operation.


(4)Training:CANMAX offer perfect facilities and comfortable environment and can provide training services to different users. The training sessions include product training, operation training, maintenance know-how, technical know-how training, standards, laws and regulations training and other training, all of which are tailored to fulfill your individual needs. Training programs can be conducted in our factory field, or at the client's site.


(5)Technical Advice: CANMAX can also help customers to coordinate with trained service personnel and provide you with detailed and extensive knowledge. Through our technical advice, your machine life can be significantly extended and sustained high capacity.





casesWe have already exported our products to more than 100 countries and regions, including: Africa, the Middle East, South America, Central Asia, Russia, Mexico, Australia, New Zealand, Holland, British, Mongolia and so on.
