Underground Low Profile Mining Dump Truck 12 Tons
- Category: Dump Trucks >>>
- Supplier: Henan,Jialongli,Imp&Exp,Trading,Co.,Ltd.
Share on:
Product Overview
Description
Products Description
12T Underground Dump Truck
UT120 is a mining dump duty truck produced based on EJC20 for various underground mines. It is suitable for trackless transportation operations in underground tunnels and engineering construction tunnels with a working face larger than 3.2×3.2meters. The standard volume is 6m³, and the maximum traction force can reach 150kN.
FEATURES
▲High Efficiency and High Reliability
UT120 is powered by Yuchai engine with powerful turbocharged, electronically controlled high-pressure common rail, and Pure mechanical transmission ensures better fuel economy., The transmission system adopts the DANA torque converter, gearbox and drive axle which have been deeply adjusted. The system has good stability and higher work efficiency.
▲Easy Maintenance
Daily maintenance can be done on the ground level;
Central lubrication and pressure testing system. Normally closed wet drive axle, limited slip reducer, braking without high temperature and without slip;
▲Comfortable
The cab adopts a shock-resistant and comfortable lateral fully enclosed room, equipped with air conditioning, electric shift, accelerator pedal and seat are all ergonomic, comfortable sitting posture and flexible operation can effectively reduce the operator's work intensity;▲ Safety
The cargo box adopts high-strength wear-resistant plate NM450, which has a longer service life;
The cargo box adopts high-strength wear-resistant plate NM450, which has a longer service life;
Eaton hydraulic hose, German standard PVBR wire, IP67 waterproof and dustproof connector, more reliable electro-hydraulic;
10 micron hydraulic oil filtration before leaving the factory twice to protect hydraulic components, centralized lubrication, up to 80% of routine maintenance can be maintained on the ground, and better serve customers from a professional perspective;
APPLICABLE INDUSTRIES
▲Underground Non-coal Mine
▲Tunnel construction
Product Paramenters
SPECIFICATION | ||
Model | UT120 | |
Capacity | 12500 kg | |
Dimensions ( W×H×L) | 7725*2310*2350 mm | |
Loading height | 2256 mm | |
Unload height | 5132 mm | |
The maximum traction force | 150 kN | |
Bucket | 6 m³ | |
DIESEL ENGINE | ||
Model | YC6J175-T302 | |
Power | 129 KW | |
Cooling Form | Water cooling | |
TURNING RADIUS | ||
Maximum Steering Angle | ±70° | |
Minimum Steering Inner Diameter | 3610 mm | |
Minimum Steering Outer Diameter | 6435 mm | |
Details
High Reliability
Renowned and reliable hydraulic components are used,including PERMCO hydraulic pumps,
EATON hydraulic hoses and REXROTH valves
DANA power train components.
EATON hydraulic hoses and REXROTH valves
DANA power train components.
Ergonomical Operation
All instruments, gauges and alarms are integrated into one control panel;The positions of the steering wheel and the working level are ergonomically designed.The blind zone area is largely reduced thanks to the wider visual angle from the canopy.
Better Fuel Consumption and
Efficiency
Efficiency
The optimized design and matching
between the engine and powertrain components, contribute toa better fuel consumption; The unique haul box design and shape contribute to be abetter hauling eficiec.
between the engine and powertrain components, contribute toa better fuel consumption; The unique haul box design and shape contribute to be abetter hauling eficiec.
