Concrete Paving Slip Form Machine Road Concrete Curb Slipform Machine Kerb Stone Drainage Ditch Curb Roadside Machinery
- Category: >>>
- Supplier: Shandong Vanse Machinery Technology Co. Ltd.
Share on (1601028474759):
Product Overview
Description
PRODUCT DISPLAY
SPECIFICATION
WS1400 SLIPFORM MACHINE TECHNICAL PARAMETERS | ||||||
Overall Machine Width | 2400mm | Engine Manufacturer Model | Cummins QSB4.5 | |||
Machine Height | 2450mm | Number Of Cylinders | 4 | |||
Total Machine Length | 6000mm | Maximum Torque | 600N.m @ (1500rpm) | |||
Minimum Left Turn Radius | 700mm | Maximum Power | 97KW @ (2200rpm) | |||
Minimum Right Turn Radius | 6000mm | Maximum Torque Point Power | 94KW @ (1500rpm) | |||
Walking Speed | 0-22m/min | Maximum Speed | 2200rpm | |||
Speed Of Work | 0-15m/min | Fuel Tank Volume | 400 | |||
Lifting Height Of Outriggers | 900mm | Water Tank Volume | 400 | |||
Mold Lifting Height | 500mm | Hydraulic Oil Tank Volume | 330 | |||
Steering Mode | Front Wheel Steering | Number Of Walking Tracks | Three Tracks | |||
Number Of Vibration Interfaces | 6 Ways | Total Weight Of Equipment | 11 T | |||
DETAILS
APPLICATION
COMPANY INTRODUCTION
