Autel MaxiTPMS TS900 Car OBD2 Scanner Tool TS 900 Vehicle Universal TPMS Sensor programming Professional Altar Diagnostic Tools
- Category: >>>
- Supplier: Shenzhen Zhimu E-Commerce Co. Ltd.
Share on (1601036404552):
Product Overview
Description
Products Description
Autel MaxiTPMS TS900
Full TPMS Functions, All System Diagnostic, Program MX-Sensor, DoIP&CAN FD
Item | Description | ||
Tablet | Recommended Use | Indoor | |
Operating System | AndroidTM 11 | ||
Processor | Quad-Core (1.8 GHz) | ||
Memory | 4 GB RAM & 64 GB ROM | ||
Display | 8-inch LCD screen with 1280 x 800 resolution | ||
Rear Camera | 8 MP | ||
Connectivity | • Wi-Fi • USB 2.0, Type C • BT • Mini SD Card (supports up to 64 GB) | ||
Sensors | Ambient light sensor for brightness auto changing | ||
Audio input/output | Input: N/A Output: buzzer | ||
Power and Battery | • 3.7 V/7700 mAh lithium-polymer battery • Charges via 5 V DC power supply | ||
Tested Battery Life | Around 7 hours of continuous use | ||
Battery Charging Input | 5 V/3 A | ||
Power Consumption | Approx. 600 mA (LCD on with default brightness, Wi-Fi on) @3.7 V | ||
Operating Temp. | 0 to 50 °C (32 to 122 °F) | ||
Storage Temp. | -10 to 60 °C (14 to 140 °F) | ||
Operating Humidity | 5% to 95% non-condensing | ||
Dimensions (W x H x D) | 1259.87 mm (10.23”) x 168.98 mm (6.65”) x 33.60 mm (1.32”) | ||
Net Weight | 998 g (2.2 lbs) | ||
Protocols | ISO9141-2, ISO14230-2, ISO15765, K/L-Line, Flashing Code, SAE-J1850 VPW, SAE-J1850PWM, ISO11898 (High-speed, Middle-speed, Low-speed and Single-wire CAN, fault-tolerant CAN), SAE J2610, GM UART, UART Echo Byte Protocol, Honda Diag-H Protocol, TP2.0, TP1.6, DoIP, CAN FD | ||
V150 | Communication | BR + EDR | |
Wireless Frequency | 2.4 GHz | ||
Input Voltage Range | 8 to 30 V DC | ||
Supply Current | 150 mA @ 12 V DC | ||
Operating Temp. | 0 to 50 °C (32 to 122 °F) | ||
Storage Temp. | –10 to 60 °C (14 to 140 °F) | ||
Dimensions (L x W x H) | 77.47 x 46.8 x 21.38 mm (3.05” x 1.84” x 0.84”) | ||
Weight | 51.5 g (0.11 lbs) | ||
【Must-Have All-in-One Tool】
The Autel TS900 scanner is the ultimate upgrade from the TS608/ MX808/ MK808/ MX900 models. It seamlessly integrates comprehensive whole-system diagnostics, full TPMS functions, bi-directional control, complete 40+ services, and Bluetooth connectivity. The cost is far less than purchasing the specialty tools with these functions separately. With its exceptional capabilities, the Autel TS900 is undeniably the top choice for professional auto shops and tire repair centers. and more new features: WiFi Print, Pre&Post Scan, TPMS Tetrofit & ToolKit, FCA Renault SGW. Compatible With Tesla TPMS Sensor, Reads 315MHz,433MHz,434MHz, and 2.4GHz BLE Bluetooth Sensors.
【Complete TPMS Functions】
The Autel TPMS tool TS900 is a top-of-the-line device that offers a complete range of TPMS functions, surpassing even the comprehensive diagnostic device MS906 TS. which provides comprehensive TPMS health checks, sensor programming , TPMS relearning, all-system diagnostics, and service functions. Additionally, it offers an auxiliary ToolKit menu for even more comprehensive TPMS services compared to other devices. Elevate your TPMS experience with the Autel TS900.
【OE-Level Active Test】
The Autel TS900 is equipped with a comprehensive range of active tests, typically found only on professional bi-directional scan tools. These tests allow professionals to control and activate various actuators such as ABS, windows, doors, solenoid valves, wipers, headlights, and more, enabling them to perform specific movements and spot problems without manual intervention. making it an invaluable tool for both DIYers and mechanics.
【OE-Level Full Systems Diagnostics】
With the maxitpms TS900 automotive scanner, you can perform the same level of diagnostics as the MS906BT/MS906PRO, enabling a thorough examination of your car's ENGINE, TRANSMISSION, ABS, SRS, SAS, TPMS, A/C system, and more. including read live data, retrieve ecu information, read/erase codes and freeze frame to turn off the warning light related. Keep driving safer with the OE-level Full Systems Diagnostics of the Autel TS900.
【40+ Services】
The Autel TPMS scanner TS900 offers an extensive range of maintenance features, similar to the popular MK808TS diagnostic scanner. It includes essential functions required by repair shops, such as Oil, SAS, BMS, TPMS, Throttle, Injector, IMMO, Cylinder, etc. It allows fine-tuning with most vehicles and has a procedure guide to walk you through them.Please note that not all functions may be available for every vehicle, so please contact us if you have any compatibility concerns.
【Exclusive TOOLKIT, Special TPMS Features】
The Autel TS900 scan tool boasts a distinctive feature set not found in previous TPMS devices like the MS906TS, TS508, or TS601. Its exclusive TOOLKIT includes several advanced functions such as Check MX-Sensor ID, which displays data from MX-Sensors, Unlock REDI 7002A, Unlock Toyota ECU, as well as waking and setting them to Park Mode. These specialized features enhance the TPMS capabilities of the TS900
【AutoAuth Access for FCA Vehicles】
No more spend extra cost to buy 12+8 adapter! Now update the device system and vehicle software to newest version, 2024 Autel scanner can full access to protected FCA vehicles! With an authenticated AutoAuth account, you can access''Auto Auth'' gateway for 2022 and newer FCA vehicles(Chrysler/JEEP/Dodge/Fiat) in the US, Canada,and Mexico to perform diagnostic! Please contact us if you have any questions before purchasing
The Autel TS900 scanner is the ultimate upgrade from the TS608/ MX808/ MK808/ MX900 models. It seamlessly integrates comprehensive whole-system diagnostics, full TPMS functions, bi-directional control, complete 40+ services, and Bluetooth connectivity. The cost is far less than purchasing the specialty tools with these functions separately. With its exceptional capabilities, the Autel TS900 is undeniably the top choice for professional auto shops and tire repair centers. and more new features: WiFi Print, Pre&Post Scan, TPMS Tetrofit & ToolKit, FCA Renault SGW. Compatible With Tesla TPMS Sensor, Reads 315MHz,433MHz,434MHz, and 2.4GHz BLE Bluetooth Sensors.
【Complete TPMS Functions】
The Autel TPMS tool TS900 is a top-of-the-line device that offers a complete range of TPMS functions, surpassing even the comprehensive diagnostic device MS906 TS. which provides comprehensive TPMS health checks, sensor programming , TPMS relearning, all-system diagnostics, and service functions. Additionally, it offers an auxiliary ToolKit menu for even more comprehensive TPMS services compared to other devices. Elevate your TPMS experience with the Autel TS900.
【OE-Level Active Test】
The Autel TS900 is equipped with a comprehensive range of active tests, typically found only on professional bi-directional scan tools. These tests allow professionals to control and activate various actuators such as ABS, windows, doors, solenoid valves, wipers, headlights, and more, enabling them to perform specific movements and spot problems without manual intervention. making it an invaluable tool for both DIYers and mechanics.
【OE-Level Full Systems Diagnostics】
With the maxitpms TS900 automotive scanner, you can perform the same level of diagnostics as the MS906BT/MS906PRO, enabling a thorough examination of your car's ENGINE, TRANSMISSION, ABS, SRS, SAS, TPMS, A/C system, and more. including read live data, retrieve ecu information, read/erase codes and freeze frame to turn off the warning light related. Keep driving safer with the OE-level Full Systems Diagnostics of the Autel TS900.
【40+ Services】
The Autel TPMS scanner TS900 offers an extensive range of maintenance features, similar to the popular MK808TS diagnostic scanner. It includes essential functions required by repair shops, such as Oil, SAS, BMS, TPMS, Throttle, Injector, IMMO, Cylinder, etc. It allows fine-tuning with most vehicles and has a procedure guide to walk you through them.Please note that not all functions may be available for every vehicle, so please contact us if you have any compatibility concerns.
【Exclusive TOOLKIT, Special TPMS Features】
The Autel TS900 scan tool boasts a distinctive feature set not found in previous TPMS devices like the MS906TS, TS508, or TS601. Its exclusive TOOLKIT includes several advanced functions such as Check MX-Sensor ID, which displays data from MX-Sensors, Unlock REDI 7002A, Unlock Toyota ECU, as well as waking and setting them to Park Mode. These specialized features enhance the TPMS capabilities of the TS900
【AutoAuth Access for FCA Vehicles】
No more spend extra cost to buy 12+8 adapter! Now update the device system and vehicle software to newest version, 2024 Autel scanner can full access to protected FCA vehicles! With an authenticated AutoAuth account, you can access''Auto Auth'' gateway for 2022 and newer FCA vehicles(Chrysler/JEEP/Dodge/Fiat) in the US, Canada,and Mexico to perform diagnostic! Please contact us if you have any questions before purchasing
• Comprehensive coverage for TPMS
• Program AUTEL MX-Sensors to replace 99% of TPMS sensors on the vehicles on the road today.
• Industry-leading Relearn-by-OBD vehicle coverage.
• Compatible with 315MHz, 433/434MHz and 2.4GHz (BLE) frequency TPMS sensors.
• Cover U.S., European, and Asian vehicles, 1996 and newer to provide professional diagnostic service.
• Support all system diagnostics (including Read and Erase codes, View Freeze Frame data, View and Graph Live Data, and Perform bi-directional Active Tests and Special Functions).
• Extensive Service Menu with direct access to over 38+ maintenance services.
• Supports the latest communication protocols, including CAN FD/DoIP.
• Generate Detailed Pre- and Post-Scan Reports. Cloud-based Report Management allows you to view, save, print, and share reports on mobile phones, tablets, and computer browsers.
• Auto-VIN technology automatically identifies vehicle make, model, and year.
• 8-inch touchscreen with 1024 x 600 resolution display and 8-megapixel rear camera.
• 64GB onboard memory for fast processing and access to the software.
• Android 11 operating system for fast boot-up and operation speed.
• Program AUTEL MX-Sensors to replace 99% of TPMS sensors on the vehicles on the road today.
• Industry-leading Relearn-by-OBD vehicle coverage.
• Compatible with 315MHz, 433/434MHz and 2.4GHz (BLE) frequency TPMS sensors.
• Cover U.S., European, and Asian vehicles, 1996 and newer to provide professional diagnostic service.
• Support all system diagnostics (including Read and Erase codes, View Freeze Frame data, View and Graph Live Data, and Perform bi-directional Active Tests and Special Functions).
• Extensive Service Menu with direct access to over 38+ maintenance services.
• Supports the latest communication protocols, including CAN FD/DoIP.
• Generate Detailed Pre- and Post-Scan Reports. Cloud-based Report Management allows you to view, save, print, and share reports on mobile phones, tablets, and computer browsers.
• Auto-VIN technology automatically identifies vehicle make, model, and year.
• 8-inch touchscreen with 1024 x 600 resolution display and 8-megapixel rear camera.
• 64GB onboard memory for fast processing and access to the software.
• Android 11 operating system for fast boot-up and operation speed.
The TS900 offers advanced diagnostics, comprehensive TPMS, and an extensive one-touch service menu. The MaxiTPMS TS900 is an 8-inch TPMS, Diagnostics and Service, touchscreen tablet. The TS900 can activate, read and relearn all known TPMS sensors, including Tesla OE sensors, and program the Autel 1-Sensor to replace 99 percent of the TPMS sensors on the road today. The TS900 is also compatible with the Autel Bluetooth-TPMS sensors (BLE-A001), preprogrammed for Tesla models and programmable for BLE-equipped vehicles. Diagnostic functions include all systems Pre/Post Scans, bi-directional Active Tests, and Special Functions. Quickly execute 38-plus service functions. TS900 offers an advanced processor, 4GB operating memory, and 64 GB storage memory and runs on Android 11.
About Autel
FAQ
How long its warranty, if the purchase back to find a problem how to contact the buyer?
We are Autel Official Shop In Alibaba. All the products we are selling are genuine with a one-year warranty
and lifetime after-sales service starting from the date of the original purchase.
About Shipping?
1. We can ship from overseas warehouse in US/CA/UK/DE/RU/AU etc.
2. We can provide Fast shipping & Save customs tax for you !
3.We support DHL, UPS, FEDEX, TNT, EMS etc logistics methods as you need .
3.We support DHL, UPS, FEDEX, TNT, EMS etc logistics methods as you need .
4. We support 10 day delivery guarantee,shipped in 3-7 workdays after payment.
Become our authorized reseller?
We accept Paypal, T/T and Bank Transfer.
Bulk purchase / More discounts?
We will quote in real time for you.
What languages does the device support?
You can tell us the device model you want, and our technical staff will reply you in 2 hours.
In general, our device supports English, German, Spanish, French, Traditional Chinese, Japanese, Polish, Portuguese,Russian, Italian, Korean, Dutch, Swedish etc.
(some support Persian, Hebrew, Indonesian;MS906S and elite II support other minor languages)
Can it do ECU programming and program keys?
Some products support ECU programming and program keys function,please contact us, we will patiently answer for you.
How can i know if my model is supported by the diagnostic device?
Please contact us and provide below information, then we can check the compatibility for you：1.Car Makes, Model / 2.Year / 3.VIN
4.Engine Model / 5.Function of scanner you need most
4.Engine Model / 5.Function of scanner you need most
What vehicle brands do you support?
Our diagnostic tools support 104+ vehicle models, for which you can refer to the compatibility list below:
