Traction | 8X4 | ||
Driving type | LHD (RHD is option) | ||
Cabin | HW76 Cab, with one sleeper bed, two seats, with A/C | ||
Type | Forward control cab, hydraulically tiltable by 60° | ||
Construction | Current standard all steel construction | ||
Engine | Brand | SINOTRUK | |
Model | WD615.47 371hp | ||
Displacement | 9.726 L /Diesel | ||
Max. output | 371hp@2200rpm | ||
Max. torque | 1500Nm @1100-1600 rpm | ||
Gear box | Model | HW19710 | |
Brand | SINOTRUCK | ||
Type | 10 Forward& 2 Reverse | ||
Clutch: | Φ430 Diaphragm type, Single dry frictional disc, Hydraulic boosting hydraulically operating with air assistance | ||
Steering | Model | ZF8098 | |
Tyre | Tyre | 12.00R20 Tyres | |
Fuel tank | 300L Iron Tank with locking fuel cap, fitted to the off side of the chassis | ||
Front axle: | HF9 tons front axle with drum brake | ||
Rear axle | HC16 16tons | ||
Tipper Bucket | Body size(mm):6800×2300×1800 |
