ALEX ECU FLASHER Best Software READ WRITE ECU 2021

Product Overview

Description

ALEX ECU FLASHER Best Software READ WRITE ECU 2021



Alex Flasher Full + One Pcs PC+ Instruction (Win7 Version)

194 MB - Cloud Mega



Included files:

AF-keygen.rar

Alex ECUF_+instruction (ENG) Windows 7.rar
Alex Flasher installation file only Win7.rar
Flasher.txt
FLASHER_Alex.pdf
installation instructions! ENG.pdf
Read me!.txt
Sid 208 Help.rar
Software.rar





Alex ECU Flasher is a Universal loader for reading and writing flash memory of the computer via CAN bus and k-line, which includes several software products designed to work with various types of computers: ECUF Flasher, Honda Flasher (Acura flasher), Denso ECU Flasher, Toyota flasher / Lexus flasher / Scion flasher / Hino flasher (Gen1 and Gen2).

Work with eeprom and correction of the checksum of the firmware is also supported for many blocks.
The software package complements the software for the repair of Airbag control units. All products work with the Senselock security key and come in a modular fashion!

As an adapter, a J2534 device is used, for example CarDaq, SM2 Pro or OpenPort 2.0.The developer recommends using

Genuine OpenPort 2.0, as the most stable adapter. The efficiency of the modules was tested with this adapter.



Distinctive features of the flasher are high speed and reliability of operation, support for a large number of control units, convenient selection of the type of unit by make and model of the ECU. To date, the bootloader has no analogues in the global software market, since it is the most affordable software product supporting such a number of control units. Let us do well on the capabilities of the various parts of the complex in more detail.







List of what has been tested!



HONDA – ACURA



HITACHI SH72543,

MATSUSHITA SH7058,
PANASONIC SH72543,
CONTINENTAL, TEMIC MPC5554,
KEIHIN MPC5566,
KEIHIN SH72543,
KEIHIN SH7058.
Identification, reading and writing ECU via CAN-bus via OBD2 connector, checksum correction. Reading / deleting DTC errors.
ECU / Honda / Accord / 3.5 V6 250CV / HITACHI 37820-5G0-A5X SH72543 2048kb CAN BUS.
ECU / Honda / Pilot / 3.5 V6 250CV / Continental 37820-RN0-B2X MPC5554 2mb CAN BUS.
ECU / Honda / Pilot / 3.5 V6 250CV / Continental 37820-RN0-B3X MPC5554 2mb CAN BUS.
Hyundai Starex 2.5 CRDI Denso SH72546,
Kia Bongo 2.5 CRDI Denso SH72546.
Reading and writing via CAN BUS, automatic checksum correction
+ block unlocking in BSL + password reading.
Cars DongFeng, Yutong, GAZ – GAZelle NEXT, MAZ, KAMAZ.
DELPHI MT80 Chinese Cars: Great Wall, Geely, Luxgen, BAIC Senova (Shenbao) etc.
DELPHI MT86 Korean Cars: Kia, Hyundai.
DELPHI MT92 Great Wall TriCore TC1767 mcu.
TagAz Road Partner, TaGeR, SsangYong Musso, Korando mcu C167 AM29F400, AM29F200.
2.0L, 2.4L SIM2K-140
2.0L, 2.4L SIM2K-142
2.0L, 2.5L SIM2K-D160
2.0L, 2.4L SIM2K- 341
Reading, writing, checksum correction.
reading and writing ecu by CAN BUS
reading and writing ecu by K-Line
automatic checksum correction.
Reading, writing, checksum correction.
reading and writing ecu by CAN BUS
reading and writing ecu by K-Line
automatic checksum correction.
Kia, Hyundai, Siemens SIM2K ECU, cpu TriCore SAK-TC1767
2.0L, 2.0T SIM2K-240/241/242/245
Reading, writing, checks checks
reading and writing ecu by CAN BUS
automatic checksum correction.
Ssangyong (test), Siemens SIM2K-C201 ECU, cpu TriCore SAK-TC1767
Reading, writing, checksum correction.
reading and writing ecu by CAN BUS
automatic checksum correction.
Kia, Hyundai Siemens SIMK cpu C167 flash control unit AM29F400
Read – Write – Checksum Correction.
reading and writing ecu by K-Line
Kia, Hyundai SIMK47 ECU
reading and writing ecu by CAN BUS
automatic checksum correction.
Automatic checksum correction. Kia, Hyundai Bosch ECU.
ME17.9.11 / ME17.9.12 / ME17.9.13.
MED (G) 17.9.8.
M (G) 7.9.8.
write ecu on CAN BUS.
ME17.9.21 TC1724 read, write, checksum correction.
VALEO V46 SH72544, DELPHI DCM3.5 processor MPC5566, DELPHI DCM3.4 processor SH7059.
Hummer / GMC / Pontiac / Buick / Cadillac / Chevrolet / Opel / Saab
Continental GPEC SIM90 MPC561 2048kB
Continental GPEC2 MPC5566 3Mb
Reading and writing ecu by CAN BUS without digital signature correction.
Continental GPEC2 MPC5566 3Mb
Reading FULL FLASH.
Record (CAL + SOFT) FLASH.
Identification, checksum correction.
ecu Delphi DCM3.7, reading and writing ecu by CAN BUS mcu SH72543 without digital signature correction.
ecu SIMOS 7.1, SIMOS 7.1A, SIMOS 9.1 flash AM29F400 read PCM record on K-Line.
ecu SIMOS 3, SIMOS 3.2, SIMOS 3.2A, SIMOS 3PC, SIMOS 3PD, SIMOS 3PB, SIMOS 3PE, SIMOS 3PCA, SIMOS 3PA, SIMOS 3PG, SIMOS 3.3A, SIMOS 3.4, SIMOS 3.4A read PCM write
Volkswagen, Skoda, Seat, Audi, VAG, BOSCH MED17-EDC17 TP2.0 CAN BUS ECU recording, checksum correction. (TEST)
SsangYong Rexton, Korando, Action ecu Delphi DCM3.7, read and write ecu by CAN BUS mcu SH72513.
Siemens Continental EMS3125 TriCore TC1782 read and write ecu by CAN BUS
Suzuki Swift Denso MCU SH7058 K-Line recording.
Suzuki Grand Vitara 2.4l Denso MCU SH7058 record on CAN BUS.
Reading and writing flash. Reading and writing eeprom: – INT FLASH, EEPROM: TC1791-384, TC1791-512, TC1762, TC1766, TC1738, TC1767, TC1797, TC1724, TC1728, TC1782, TC1784, TC1793, TC1798. – INT FLASH, INT FLASH + EXT FLASH, EXT FLASH, EEPROM: TC1796.



• Modules Honda Flasher (Acura Flasher):


• Honda CAN-Bus FULL
  Supported blocks:
  HITACHI SH72543
  ECU / Acura / TLX / 3.5 V6 280CV / HITACHI 37820-5J2-A5X SH72543 2048kb CAN BUS.
  Continental – TEMIC MPC5554
  Kia, Hyundai DENSO SH72546
  Reading and writing ecu by CAN BUS, automatic checksum correction.
  Isuzu Transtron SH7058, 4JJ1, 4HK1, 6HK1
  Reading and writing ecu on CAN BUS. Automatic checksum correction
  PSA Siemens Continental SID208 TriCore TC1797
  PSA Peugeot Citroën Siemens Continental SID208 TriCore TC1797.
  Cummins CM2150 and CM2220
  Read Full Flash, record calibrations. Read and write via J1939 (CAN BUS) protocol. Additional function – Reading and writing configuration.
  DELPHI MT80 / 86/92
  Reading and writing, automatic checksum correction.
  Siemens VDO MSE3.5
  Reading and writing ecu on K-Line, automatic checksum correction.
  Kia, Hyundai, Chevrolet SIM2K, SIMK + SIMK47
  Kia, Hyundai ecu Siemens SIM2K, cpu MPC561
  SIM2K-D160 cpu MPC561
  Kia, Hyundai BOSCH
  Kia, Hyundai, ecu BOSCH EDC17C08 TriCore TC1766 processor and BOSCH EDC17CP14, TriCore TC1796 processor Record ecu via CAN BUS.
  Iveco BOSCH EDC16C39
  Reading PCM record on K-Line ecu BOSCH EDC16C39 UAZ (with Iveco engine).


• VAZ, UAZ Bosch


• Reading – Writing an ecu via CAN BUS Bosch ME17.9.71 TriCore TC1724, + Unlocking the unit in BSL mode.


• Citroen – Peugeot VALEO


• Reading and writing ecu by CAN BUS, automatic checksum correction
  Delphi ACDelco, GM SIMTEC, GM BOSCH
  Reading and writing ecu by CAN BUS, automatic checksum correction.


• Chrysler, Dodge, Jeep, Fiat


• Reading and writing ecu by CAN BUS without digital signature correction.


• Continental GPEC SIM90 MPC561 2048kB


• VAG Modules:


• VAG 1


• VAG 2 ECU Siemens SIMOS PPD1.1, PPD1.2, PPD1.3, PPD1.5 MPC561 read and write ecu by K-Line.


• VAG 3 Volkswagen, Skoda, Seat, Audi, VAG, BOSCH MED17-EDC17 UDS CAN BUS ECU recording, checksum correction. (TEST).


• SsangYong Delphi


• Renault


• Siemens EMS 3132 module read and write ecu on K-Line.


• Suzuki Denso petrol cars with SH7058 processor


• Suzuki SX4 Denso MCU SH7058 CAN Bus Record. Suzuki SX4 ver.2 Denso MCU SH7058 record on CAN BUS.


• Ford Modules:


• Ford Fiesta 1.25L, 1.4L Sigma Ti-VCT EMS2102 reading and writing ecu via CAN BUS.


• AIRBAG – SRS Modules


• AIRBAG module – SRS Toyota, Subaru


• Toyota DENSO Airbag – SRS processor RENESAS H8SX, R5F6 (256kb, 512kb). Subaru DENSO Airbag – SRS on a RENESAS H8SX, R5F6 (256kb, 512kb) processor. Supports read and write flash via CAN BUS.


• AIRBAG Module – SRS Kia, Hyundai


• Kia, Hyundai Airbag – SRS on processor MAC7242, SAK-XC2361A. Supports reading and writing eeprom over CAN BUS.


• Module AIRBAG – SRS Nissan – Infiniti


• The Nissan – Infiniti module is designed to work with the SRS AIRBAG AUTOLIV unit with an infineon XC2336B processor. Reading and writing eeprom SRS over CAN BUS


• AIRBAG module – SRS Honda – Acura, Subaru


• Subaru Honda – Acura DENSO Airbag – SRS with RENESAS H8SX, R5F6 (256kb, 512kb) processor. Delete impact data in the AirBag block.


• AIRBAG module – SRS Renault


• Deletion of impact data in the AirBag unit by OBD. Continental Airbag – SRS on SPC560 processor.
  AIRBAG module – SRS Renault K-Line OBDII


• Modules Toyota, Lexus, Scion, Hino Flasher


• GEN1


• Supported Units: ECU, AT, CVT. Processor based ECUs: SAK-TC1766 (Test), ST10F275 (Test), MPC565, SH72512, SH72513, SH72544, SH72546, 76F004, 76F0012, 76F0015, 76F0021, 76F0038, 76F0039, 76F0040, 76F0070, 76F0085.


• Infineon Tricore BSL Module


• Infineon Tricore BSL TC1724 / TC1738 / TC1762 / TC1766 / TC1767 / TC1791 / TC1793 / TC1796 / TC1797 / TC1798 – boot mode.
