Factory sale various vertical machining center price cheap cnc machining center
- Category: >>>
- Supplier: Nantong Sunway Science And Technology Development Co. Ltd.
Share on (1601201081458):
Product Overview
Description
Product Description
Specification
Machine Type | Unit | VMC1060(line rail) | ||
Worktable | ||||
Worktable(length×width) | mm | 1300×600 | ||
Maximum load of table | kg | 1000 | ||
T-slot(number of slot × slot width × pitch) | mm | 5-18×120 | ||
Triaxial itinerary | ||||
Travel for X/Y/Z axes | mm | 1000/600/650 | ||
Distance from spindle nose to table surface | mm | 150-800 | ||
Distance from spindle center to column guide surface | mm | 700 | ||
Feed system | ||||
CNC system | FANUC-Oi MD | |||
Rapid shift of axes of X/Y/Z | m/min | 24/24/20 | ||
Maximum cutting feed speed | m/min | 8 | ||
Automatic tool transform system(CNC milling without) | ||||
Standard tool quality | bundle | Disc type 24 | ||
The largest diameter cutter knife/length | mm | Φ80 Tool/300 | ||
Tool exchanging manner | Air-operated | |||
Average tool exchanging time | sec | Disc type: 2.5s | ||
Precision | ||||
Positioning accuracy | mm | 0.008 | ||
Accuracy of repeated positioning | Mm | 0.005 | ||
Spindle system | ||||
Spindle speed | r.p.m | 8000 | ||
Spindle specifications(model/installation diameter) | BT40/150 | |||
Drive manner of spindle | Belt drive | |||
Motor power of spindle | kw | 11/15 | ||
Air pressure | ||||
Requirements for air compressing | Kg/cm² | ≥6 | ||
Air pressure flux | m³/min | ≥0.3 | ||
Machine specifications | ||||
Integrated weight(kg) | kg | 7000 | ||
Overall dimension(weight×width×height) | mm | 3500×2700×2650 | ||
Company Profile
Nantong Sunway Technology Co., Ltd. specializes in producing Electric Discharge Machines, Machining Centers, High Speed Engrave Milling Machines, CNC Gantry Type Machining Centers and relevant bodies. Our products have been utilized directly by well known OEM manufacturers in India, Korea, Taiwan Area and Hong Kong. Moreover, we mainly export our products to Italy, Poland, Korea, Southeast Asia and South America.
"Excellent quality, competitive price, and thoughtful service" are the development factors of our enterprise. We guarantee to provide management rules in purchasing, processing, equipment and craftwork administration. Also, we have professional staff for testing and inspection. Our target is ''to be the best of all".
"Excellent quality, competitive price, and thoughtful service" are the development factors of our enterprise. We guarantee to provide management rules in purchasing, processing, equipment and craftwork administration. Also, we have professional staff for testing and inspection. Our target is ''to be the best of all".
FAQ
1. who are we?
We are based in Jiangsu, China, start from 2004,sell to Eastern Europe(40.00%),Mid East(30.00%),North America(30.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Engraving And Milling Machine,Electrical Discharge Machine,Vertical Machining Center
4. why should you buy from us not from other suppliers?
we have more than ten years design and research experience
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,Cash,Escrow;
Language Spoken:English,Chinese
We are based in Jiangsu, China, start from 2004,sell to Eastern Europe(40.00%),Mid East(30.00%),North America(30.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Engraving And Milling Machine,Electrical Discharge Machine,Vertical Machining Center
4. why should you buy from us not from other suppliers?
we have more than ten years design and research experience
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,Cash,Escrow;
Language Spoken:English,Chinese
