High accuracy Fanuc Control Vertical China Countertop 3axis Vertical Milling Machines Cnc Machining Center with Atc
High-accuracy Fanuc Control Vertical China Countertop 3axis Vertical Milling Machines Cnc Machining Center with Atc
High-accuracy Fanuc Control Vertical China Countertop 3axis Vertical Milling Machines Cnc Machining Center with Atc
High-accuracy Fanuc Control Vertical China Countertop 3axis Vertical Milling Machines Cnc Machining Center with Atc
High-accuracy Fanuc Control Vertical China Countertop 3axis Vertical Milling Machines Cnc Machining Center with Atc
High-accuracy Fanuc Control Vertical China Countertop 3axis Vertical Milling Machines Cnc Machining Center with Atc

High accuracy Fanuc Control Vertical China Countertop 3axis Vertical Milling Machines Cnc Machining Center with Atc

Share on (1601201317784):


Price:$28,570.00 - $35,720.00

Quantity:


Product Overview

Description



Recommend Products




Products Description


222
CNC milling machine is a kind of automatic processing equipment developed on the basis of general milling machine. Their processing technology is basically the same, and their structure is also similar. CNC milling machines are divided into two categories: without tool magazine and with tool magazine. The CNC milling machine with tool magazine is also called machining center.





The surface shape of milling machine is generally composed of straight line, arc or other curves. Ordinary milling machine operator according to the requirements of the drawing. By changing the relative position between the cutter and the workpiece, and then matching with the selected milling cutter speed, the cutter can cut the workpiece, and then various workpieces of different shapes can be processed.



1. It has strong adaptability and good flexibility in parts processing, and can process parts with complex contour shape or difficult to control size, such as mold parts, shell parts, etc;

2. It can process parts that can not be processed by ordinary machine tools or are difficult to process, such as complex curve parts described by mathematical models and three-dimensional curved surface parts;




Specification


Machine Type

VMC1890
Working table's size
mm
2000X900
Working table's maximum bearing capability
kg
2000
T-nuten

5`22
x axle travel
mm
1800
y axle travel
mm
900
z axle travel
mm
700
Working table to spindle's face
mm
150-850
The distance from Spindle's center to vertical guide rail
mm
950
Spindle's rotary speed
m/min
6000
Spindle's specification

BT50-190
Spindle Motor
kw
11/15
Fast-moving speed
m/min
15
Feed speed
m/min
4
Feed motor
kw
X.Y.Z;4.5
Tool shank model

MSA BT50
Blind rivet type

MSA P50T-1
ATC type (optional)

24
Appearance size
mm
4600X3600X3000
Weight
t
20.3
Pressed air
mpa
0.6
Air. consumption
l/min
500
Elecrnc Power requrent
kva
35


Company Profile




Our Service




Overseas after sales service outlets
TOPTECH SMAC MACHINERY LIMITED（Canada）
Address:Office and showroom, unit 5, 5510 Ambler Dr Mississauga, ON, L4W2V1, CANADA
Office:905 238 8912
Contact: Mrs Merry NA

COMPANY REPRESENTATIVE (EGYPT)
Address: Ibn Khaldon St. -Villa No.16-6th District-Obour City-Cairo-Egypt
Tel & Fax: +20244823499
Cell phone: +201223960211
Contact: Ahmed Refaat

SJR MACHINERY LIMITED（Algeria）
Adress: cité 128 logements Bater numéro 71 Sidi el DJILLALI sidi bel abbes 22000 att to Mr mezouar Mohammed
mobile number 0542 695 457 and 0770 551 807
Tel: 0542 695 457 ,0770 551 807
Email:Mezouarstar@gmail.com


Packing & Delivery




We choose the best packaging, the most excellent
logistics services, to ensure that your goods faster and safer to reach the destination.


FAQ


Q.What are your normal lead times?
A.Our company typical lead times range from 3-4weeks after receipt of order.

Q.What are the terms of payments you offer?
A.We accept payment of T/T, L/C, and Western Union, cash, O/A etc.

Q.What kind of package do you offer?
A.Normally in plywood case, to make sure all goods in good condition.

Q.What is the MOQ for your production?
A.The MOQ depends on your requirements for color, logo and so on. For some normal items, we have in stock, the MOQ is 1 set.

Q.Do you have CE certification
A.Yes, we have CE certification, machine quality is one year guaranteed.

Q.How to control the quality of the products?
A.We have always placed great emphasis on the quality level is maintained. Moreover, the principle we always maintain is "to provide customers better quality, better price, and better service".
