Low price new factory sales vertical CNC milling machine VMC850 milling CNC vertical machining center
Low price new factory sales vertical CNC milling machine VMC850 milling CNC vertical machining center
Low price new factory sales vertical CNC milling machine VMC850 milling CNC vertical machining center
Low price new factory sales vertical CNC milling machine VMC850 milling CNC vertical machining center
Low price new factory sales vertical CNC milling machine VMC850 milling CNC vertical machining center
Low price new factory sales vertical CNC milling machine VMC850 milling CNC vertical machining center
Low price new factory sales vertical CNC milling machine VMC850 milling CNC vertical machining center

Low price new factory sales vertical CNC milling machine VMC850 milling CNC vertical machining center

Share on (1601201965208):


Price:$14,000.00 - $18,000.00

Quantity:


Product Overview

Description









Detailed configuration


Technical Parameters
Unit
Specifications
Table size
mm
1000*500
Table maximum load
kg
600
X/Y/Z axis travel
mm
800*500*500
Distance between spindle center and column guide surface
mm
550
Distance between spindle end face and worktable surface
mm
140-740
X/Y/Z Max.feed speed
mm/min
8000
X/Y/Z Max.rapid traverse
m/min
48/48/36
The spindle maximum speed
R/min
8000
The spindle taper hole
type
BT40
Spindle motor
kw
7.5/11
X/Y/Z axis servo motor
kw
2.0/2.0/2.0
X/Y/Z motor connection
Direct connection
The workbench T slot
mm
5-18*90
Repeat positioning accuracy
mm
+0.004
Max.toll weight
kg
8
Max.toll length
mm
250/350
Electric capacity
kva
11
Machine size(L/W/H)
mm
2700*2250*2700
Net.weight(about)
kg
5500
