High Quality Black Compression F connector RG6 Coaxial Cable
US $13.99-$75.20
High performance best price RG400 High Temperature Coaxial Cable Double Braiding Shield for communication
- Category: >>>
- Supplier: Jiangsu Elesun Cable Co. Ltd.
Share on (1601207263370):
Product Overview
Description
Product Description
50 ohm low loss high temperature Coaxial Cable RG400 RF Cable with BNC male to BNC male for communication
Typical Application:Transmission of data signals in applications such as antenna feed cables or Ethernet backbones where high temperature performance is needed.
Best Feature: Lower loss than smaller diameter cable such as RG174, high temperature rating of extruding FEP jacket. The RG400 loss is widely accepted at HF frequencies. Because it is constructed with a silver plated outer conductor this prevents oxidation of the conductor which decreases loss vs time.
Custom service:
We supply RG400 cable assembly with N connector, 7/16 DIN connector, BNC connector TNC connector
Custom packing: the length can be 100m/roll, 200m/roll, 305m/ roll, or 500m/drum,1000m/drum
Perfect Service(an excellent team serving you) 24*7 hours available.
Shipment:by sea(when the goods weighs more than 100KGS), by air (when the goods weighs less than 100KGS, or by DHL or Fedex express (when the goods weighs less than 50KGS)
Description：
. Standard Mil-c-17
. Insulation Material：PTFE
. Impedance:50Ω±2
. Jacket:FEP
.Color:Light Brown
. Insulation Material：PTFE
. Impedance:50Ω±2
. Jacket:FEP
.Color:Light Brown
Typical Application:Transmission of data signals in applications such as antenna feed cables or Ethernet backbones where high temperature performance is needed.
Best Feature: Lower loss than smaller diameter cable such as RG174, high temperature rating of extruding FEP jacket. The RG400 loss is widely accepted at HF frequencies. Because it is constructed with a silver plated outer conductor this prevents oxidation of the conductor which decreases loss vs time.
Custom service:
We supply RG400 cable assembly with N connector, 7/16 DIN connector, BNC connector TNC connector
Custom packing: the length can be 100m/roll, 200m/roll, 305m/ roll, or 500m/drum,1000m/drum
Perfect Service(an excellent team serving you) 24*7 hours available.
Shipment:by sea(when the goods weighs more than 100KGS), by air (when the goods weighs less than 100KGS, or by DHL or Fedex express (when the goods weighs less than 50KGS)
RG400/U coaxial cable specifications | ||
Material of Inner Conductor | Silver Copper | |
Structure of Inner Conductor | 19/0.20mm | |
Material of Insulation | PTFE | |
Diameter of Insulation | 3.00mm | |
Material of Braiding(Shielding) | Silver Copper | |
Structure of Braiding(Shielding) | 144+168*0.15mm | |
Material of Jacket | FEP | |
Diameter of Jacket | 4.95mm | |
Working temp | -55℃/200℃ | |
Impedance | 50Ω±2 | |
Voltage | 3000V | |
Packing & Delivery
Company Profile
Q1: Are you a manufacture or a trading company?
A:We are a professional cable manufacture with more than 20 years production experience.
Q2:What kind of cable do you produce?
A: We specialized in producing Coaxial Cable,Cable Assembly,Network cable,electric wire,Network Cable.
We also provide cable assembly according to customers requirement.
Q3:What's your MOQ? Can you offer free samples?
A: Our MOQ is 2KM per item. Free samples can be sent to you if available in stock,freight cost need to be paid by your side.
Q4: What's your delivery time?
A:Normally, our delivery time is 7-10 days after received deposit or payment,it base on the quantity of the order.
Q5: What's your payment term?
A: We accept T/T, L/C,Western Union.Other payments accept through negotiation.
Q6:What's your trade term?
A: We accept FOB ShangHai or Ningbo,Guanghzou,Shenzhen,CFR,CIF,EXW term
Q7: Where is your factory located? How can I visit there?
A: Our factory is located in Zhenjiang City,Jiangsu Province,China.
1 hour drive from Nanjing Airport.
3 hours drive or 1 and a half hour by high speed rail to railway station from shanghai.
Q8:Do you accept OEM/ODM?
A:Sure.we accept.
Why choose us:
1.We have more than 20 years experience for communication cables and cable assembly.
2.We own R&D team more than 10 engineers,give you strongest support !
3.Fast delivery time ,we have big capacity with short production time.
4.Factory directly sale - Most Competitive price than average level .
5.We have very strict quality control system during the whole production process.We always inspect all the goods before shipment.
6.IATF 16949 /UL certification approved.
A:We are a professional cable manufacture with more than 20 years production experience.
Q2:What kind of cable do you produce?
A: We specialized in producing Coaxial Cable,Cable Assembly,Network cable,electric wire,Network Cable.
We also provide cable assembly according to customers requirement.
Q3:What's your MOQ? Can you offer free samples?
A: Our MOQ is 2KM per item. Free samples can be sent to you if available in stock,freight cost need to be paid by your side.
Q4: What's your delivery time?
A:Normally, our delivery time is 7-10 days after received deposit or payment,it base on the quantity of the order.
Q5: What's your payment term?
A: We accept T/T, L/C,Western Union.Other payments accept through negotiation.
Q6:What's your trade term?
A: We accept FOB ShangHai or Ningbo,Guanghzou,Shenzhen,CFR,CIF,EXW term
Q7: Where is your factory located? How can I visit there?
A: Our factory is located in Zhenjiang City,Jiangsu Province,China.
1 hour drive from Nanjing Airport.
3 hours drive or 1 and a half hour by high speed rail to railway station from shanghai.
Q8:Do you accept OEM/ODM?
A:Sure.we accept.
Why choose us:
1.We have more than 20 years experience for communication cables and cable assembly.
2.We own R&D team more than 10 engineers,give you strongest support !
3.Fast delivery time ,we have big capacity with short production time.
4.Factory directly sale - Most Competitive price than average level .
5.We have very strict quality control system during the whole production process.We always inspect all the goods before shipment.
6.IATF 16949 /UL certification approved.
