2 way Nano 1024 dmx controller or 4 way Nano Pro 2048 lighting console

Share on (1601226244280):


Price:

Quantity:


Product Overview

Description





Model number: FT-Nano01





Nano 1024 controller 2 ways:


Output circuit: one standard Art Net output port, two optoelectronic isolation standard DMX output ports.


RDM bidirectional communication: supports


Number of channels: 2 * 512 DMX channels, capable of controlling up to 64 computers with 16 channels simultaneously


Control lamp positions: Built in 600 lamp positions, up to 600 computer lamps can be connected simultaneously for control


Lamp Library Support: Built in over 7000 commonly used lamp libraries, supporting the storage of 100000 internal lamp libraries, supporting direct compatibility with four formats: r20, d4, dk, mxl, and built-in intuitive and fast lamp library writing software


Lamp attribute control: intelligent attribute pagination, a single computer lamp supports up to 512 channels


Materials and groups: up to 1000 materials and 200 light groups can be stored


Built in graphic effects: Built in rich classification of general and specialized channel graphic effects, supporting self drawn graphics and keyframe graphics, innovative graphic effects, powerful pixel mapping function, independent user graphic window, providing unlimited number of graphics, and can be run with multiple overlay effects


Graphic interface: Full Chinese graphic interface, supports custom workspace and windows, workspace windows can be freely adjusted in size and position, workspace layout can be saved, window icons and fonts can be resized, supports image naming and graffiti effect naming


Language switching: Supports switching between Simplified Chinese, Traditional Chinese, and English languages


Advanced control: Built in RGB/CMYK color palette, supports custom lighting order, replays global and single attribute time, supports lighting overlap


Playback storage: 10 playback sticks, 50 playback pages, independent playback window, up to 1000 replays can be stored


Playback playback: Supports both occupied and unoccupied playback modes, with a maximum of 10 replays played simultaneously


Number of program steps: A single playback supports storing up to 100 program steps


Centralized control conversion: The panel is equipped with 2 centralized control encoder wheels


Control System: Fully self-developed software control system based on Linux


Display screen: 10.1-inch display screen


Touch screen: Multi point capacitive touch screen


Power input: DC12V 3A


Product size: 34 * 26 * 8cm





Nano Pro 2048 controller 4 ways:


Output line: Supports 8 Art Net output ports and 4 standard DMX output ports with optoelectronic isolation.


RDM bidirectional communication: supports


Number of channels: 4 * 512 DMX channels, capable of controlling up to 128 16 channel computer lights simultaneously


Control lamp positions: Built in 600 lamp positions, up to 600 computer lamps can be connected simultaneously for control


Lamp Library Support: Built in over 7000 commonly used lamp libraries, supporting the storage of 100000 internal lamp libraries, supporting direct compatibility with four formats: r20, d4, dk, mxl, and built-in intuitive and fast lamp library writing software


Lamp attribute control: intelligent attribute pagination, a single computer lamp supports up to 512 channels


Materials and groups: up to 1000 materials and 200 light groups can be stored


Built in graphic effects: Built in rich classification of general and specialized channel graphic effects, supporting self drawn graphics and keyframe graphics, innovative graphic effects, powerful pixel mapping function, independent user graphic window, providing unlimited number of graphics, and can be run with multiple overlay effects


Graphic interface: Full Chinese graphic interface, supports custom workspace and windows, workspace windows can be freely adjusted in size and position, workspace layout can be saved, window icons and fonts can be resized, supports image naming and graffiti effect naming


Language switching: Supports switching between Simplified Chinese, Traditional Chinese, and English languages


Advanced control: Built in RGB/CMYK color palette, supports custom lighting order, replays global and single attribute time, supports lighting overlap


Playback storage: 10 playback sticks, 50 playback pages, independent playback window, up to 1000 replays can be stored


Playback playback: Supports both occupied and unoccupied playback modes, with a maximum of 10 replays played simultaneously


Number of program steps: A single playback supports storing up to 100 program steps


Centralized control conversion: The panel is equipped with 2 centralized control encoder wheels


Control System: Fully self-developed software control system based on Linux


Display screen: 10.1-inch display screen.


Support expansion; 1 external screen


Touch screen: Multi point capacitive touch screen


Power input: DC12V 3A


Product size: 34 * 26 * 8cm





Pictures:





1024 controller (1).jpg1024 controller (2).jpgNano 1024 controller (2).jpgNano 1024 controller (3).jpg










Trade Term
1. Price term: EXW price or FOB
2. MOQ: 1PCS
3. Payment: T/T, Western Union, Paypal, Cash
4. Delivery time: 1-5days after the payment
5. Shipping: By air, by sea, by DHL/Fedex/UPS/EMS
6. Guarantee period: 2 years
7. Packing: Standard export cartons or flight case
8. After sells service:If there has problem with the product, pictures or videos are necessary for us to check carefully for you, we will offer you the replace parts for free , if within 2 year's warranty.
