Product Overview

Description




DMX to SPI converter ws2812b LED light DMX 512 rgb decoder controller



Product Description





    The DMX512 Data Decoder adopted the advanced decoding technology to convert the international standard DMX512/1990 signal into standard LPD6803 / LPD8806/ TM1809/ P9813/ TLS3001/ WS2801 signals, each decoder has 96/510 DMX output channels, and the output channels can be expanded by adding decoders, therefore, most of LED lights can be controlled by DMX512/1990 protocol via the signal conversion, then widely used pixel light, digital tube light, floodlight, pixel screen, dancing floor light etc.





 802







Specification:

















































Model



BC-802- 2812b



Input Voltage



DC12V-DC24V



Input Signal



DMX512/1990



Output Signal



WS2812B



Decode Channel



512



Control LED QTY



170



Control Chip mode



TM1803, TM1804, TM1809, TM1812, UCS1903,


UCS1909, UCS1912, UCS2903, UCS2909, UCS2912, WS2811, WS2812B



DMX Socket



Standard XLR-3, RJ45 port



Size (mm)



L125*W52*H40(mm)



Weight



315 g









Control ICs type:















































 IC Type Compatible ICs Type
 2811 TM1803, TM1804, TM1809, TM1812, UCS1903, UCS1909,

 UCS1912, UCS2903, UCS2909, UCS2912, WS2811, WS2812B etc.


RGB
 2801 WS2801, WS2803, etc.
 6803 LPD6803, LPD1101, D705, UCS6909, UCS6912 etc.
 3001 TLS3001, TLS3002 etc.
 8806 LPD8803, LPD8806, LPD8809, LPD8812 etc.
 9813 P9813 etc.
 TM1814 TM1814 etc.RGBW
 SK6812 SK6812, SK6822, UCS2904 etc.





Feature:





1. Input standard DMX512 protocol,Address can be set by DIP.





2. Automatically adapt input voltage DC12V-24V.





3. Self-Changing Mode exist.





4. Output TTL Signal.





5. Power loss memory function.







Dimension:








BC-802 DMX Decoder







Wiring diagram:





1. Connect to LED strip with IC




 BC-802 DMX decoder








2. Connect to high power LED with IC





BC-802 DMX decoder  2
