Flier Factory Multirotor Drone UAV Plane 380A brushless ESC paramotor
US $108.00-$168.00
Mini Brushed Electric 30A 4 8V Speed Controller ESC Brush Electronic Motor Speed Controller For 1/24 RC Car SCX24
- Category: >>>
- Supplier: Shenzhen Dayachuangxin Technology Co. Ltd.
Share on (1601229267595):
Product Overview
Description
Recommend Products
Product Paramenters
Product Name:20A Brush ESC.
Suitable for 1/16,1/18,1/24 RC climbing car military card semi-bigfoot conversion, RC boat.
The light weight feature is also suitable for mini-Z mosquito car conversion
Functions: forward, reverse, brake
Operating voltage: 4.8V - 8.4V (suitable for 2S lithium)
Current (A): 20A
Drive frequency: 2kHz
Input: Li Po 2S/Ni-MH/Ni-Cd 4-7 batteries
Constant current: 20A, 25A <30s pulse 50A <5s
UBEC output: voltage 5.7V, current 1A
This ESC can be paired with 130/180/260/280/380 brush motors
Adjustment: ESC is fixed in the neutral zone, the new control needs to fine tune the throttle, so that the ESC light does not
light up, keep is neutral, control the throttle fine tune is TH TRIM
Suitable for 1/16,1/18,1/24 RC climbing car military card semi-bigfoot conversion, RC boat.
The light weight feature is also suitable for mini-Z mosquito car conversion
Functions: forward, reverse, brake
Operating voltage: 4.8V - 8.4V (suitable for 2S lithium)
Current (A): 20A
Drive frequency: 2kHz
Input: Li Po 2S/Ni-MH/Ni-Cd 4-7 batteries
Constant current: 20A, 25A <30s pulse 50A <5s
UBEC output: voltage 5.7V, current 1A
This ESC can be paired with 130/180/260/280/380 brush motors
Adjustment: ESC is fixed in the neutral zone, the new control needs to fine tune the throttle, so that the ESC light does not
light up, keep is neutral, control the throttle fine tune is TH TRIM
Products Description
Certifications
Payment and Shipping
Factory Tour
FAQ
Q1 : What is the Minimum Order Quantity(MOQ)?
A1: No quantity limited, Sample order or small order is acceptable, but the customers have to pay thesample cost and the courier cost.
Q2: What is the lead time?(How long will it take to prepare my goods?)
A2:2-3days for sample orders, 10-15 days for bulk orders.(The exact time will be based on therequirements)
Q3: How will you deliver my goods to me?
A3: Normally, we will ship the goods by air, by sea and by express.
Q4: Can you print my own logo on the products?
A4: Yes, of course.Not only the logo, but also the packing design and other OEM services are available.
Q5: What is your product quality?
A5: Our raw materials are all purchased from qualified suppliers. And we have very strict Qc standard toassure our final products meet your requirements.
Q6. Do you test all your goods before delivery?
A6: Yes, we have 100% test before delivery.
A1: No quantity limited, Sample order or small order is acceptable, but the customers have to pay thesample cost and the courier cost.
Q2: What is the lead time?(How long will it take to prepare my goods?)
A2:2-3days for sample orders, 10-15 days for bulk orders.(The exact time will be based on therequirements)
Q3: How will you deliver my goods to me?
A3: Normally, we will ship the goods by air, by sea and by express.
Q4: Can you print my own logo on the products?
A4: Yes, of course.Not only the logo, but also the packing design and other OEM services are available.
Q5: What is your product quality?
A5: Our raw materials are all purchased from qualified suppliers. And we have very strict Qc standard toassure our final products meet your requirements.
Q6. Do you test all your goods before delivery?
A6: Yes, we have 100% test before delivery.
