Brand New Shacman F3000 6*4 30ton Dump Tipper Truck Weichai Engine Shacman Dump Truck
- Category: >>>
- Supplier: Jinan Heavy Truck Import & Export Co. Ltd.Jinan Ltd.
Share on (1601234703146):
Product Overview
Description
Truck Brand | Shacman |
Dimension(Lx W xH) | Dimension(Lx W xH) |
Cargo body size (L*W*H, mm) | 7400x2300x1400 |
Cargo body thickness(mm) | bottom:8mm, side:6mm |
Lift type of Carriage | Ventral lifting |
Wheel base (mm) | 1800+3575+1400 |
Curb weight(kg) | 16290 |
Loading Weight(kg) | 30000 |
Fuel tanker capacity | 300L with locking fuel cap |
Fuel consumption(L/100km) | 32 |
Clutch | Single-plate dry clutch Φ420mm |
Engine | Model:WP10.380E22 Horse Power, max(kw/rpm):380HP,279/2200 Emisssion standard:EURO II |
Transmission | 12JSD200T-B,12 forwards and 2 reverse |
Steering system | ZF8118 |
Front axle | MAN 16T DOULBE REDUCTION AXLE |
Rear axle | MAN 9.5T |
Tire | 12.00R20 13 pieces |
Cab | F3000 cab, (one sleeper,with air-conditioner) |
