  • discount for lenovo Thinksystem SR630 V2 1U Rack Server case nas storage server SR630 V2 server computer
discount for lenovo Thinksystem SR630 V2 1U Rack Server case nas storage server SR630 V2 server computer
discount for lenovo Thinksystem SR630 V2 1U Rack Server case nas storage server SR630 V2 server computer
discount for lenovo Thinksystem SR630 V2 1U Rack Server case nas storage server SR630 V2 server computer
discount for lenovo Thinksystem SR630 V2 1U Rack Server case nas storage server SR630 V2 server computer
discount for lenovo Thinksystem SR630 V2 1U Rack Server case nas storage server SR630 V2 server computer
discount for lenovo Thinksystem SR630 V2 1U Rack Server case nas storage server SR630 V2 server computer
discount for lenovo Thinksystem SR630 V2 1U Rack Server case nas storage server SR630 V2 server computer

discount for lenovo Thinksystem SR630 V2 1U Rack Server case nas storage server SR630 V2 server computer

Share on (1601282047237):


Price:$2,000.00

Quantity:


Product Overview

Description



Product Description


ThinkSystem SR630 V2 is an ideal 2-socket 1U rack server for small businesses up to large enterprises that need industry-leading reliability, management, and security, as well as maximizing performance and flexibility for future growth. The SR630 V2 is based on the new 3rd generation Intel Xeon Scalable processor family (formerly codenamed "Ice Lake") and the new Intel Optane Persistent Memory 200 Series.


Lenovo SR630 V2 Server 04




Specification






















































Feature


SR630


SR630 V2


Processor


* 2x 2nd Gen Intel Xeon Scalable Processor
* Up to 28 cores & 205W per CPU
* 48x PCIe 3.0 lanes per CPU


* 2x 3rd Gen Intel Xeon Scalable Processor
* Up to 40 cores & 270W per CPU
* 64x PCIe 4.0 lanes per CPU


Memory


* 6 channels per CPU
* 24x TruDDR4 (R/LR/3DS) 2933 MHz DIMMs
* Up to 2DPC @ 2933MHz
* Max 3 TB with 24x 128 GB DIMMs
* Intel Optane PMem 100 Series


* 8 channels per CPU
* 32x TruDDR4 (RDIMM/3DS) 3200 MHz DIMMs
* Up to 1DPC & 2DPC @ 3200MHz
* Max 8 TB with 32x 256 GB DIMMs
* Intel Optane PMem 200 Series


Disk


* Up to 4x 3.5-inch or 10x 2.5-inch front bays
* 2x 2.5-inch rear SAS/SATA
* Up to 10x 2.5-inch NVMe
* 2x Internal M.2 with optional RAID 1


* Up to 4x 3.5-inch or 10x 2.5-inch or 16x EDSFF front bays
* 2x 2.5-inch rear SAS/SATA/NVMe
* Up to 12x 2.5-inch NVMe
* 2x 7mm hot-swap rear SAS/SATA/NVMe for boot
* 2x Internal M.2 with optional RAID 1


RAID


* 12Gb SAS/SATA/RAID support
* PCIe 3.0 adapters
* Range of 8-, and 16-port RAID adapters
* 8- and 16-port HBAs
* 4x Onboard NVMe ports
* NVMe switch adapter support


* 12Gb SAS/SATA/RAID support
* PCIe 3.0 and PCIe 4.0 adapters
* Onboard SATA support with RAID
* Onboard VROC NVMe support with RAID
* Wider range of 8- and 16-port RAID adapters
* 8- and 16-port HBAs
* 12x Onboard NVMe ports
* NVMe Retimer adapters for 16x NVMe


Networking


* Selectable LOM, 1GbE or 10GbE
* Optional ML2 and PCIe adapters
* 1GbE dedicated management port


* Selectable OCP 3.0, 1GbE, 10GbE or 25GbE
* Optional PCIe adapters
* 1GbE dedicated management port


PCIe


* Up to 3x PCIe 3.0 slots
* Supports 1x 75W GPU
* 1x internal RAID slot


* Up to 3x PCIe 4.0 slots
* Support 3x 75W GPUs
* 1x internal bay for cabled RAID/HBA


Management and security


* XClarity Controller with upgrades
* Full XClarity software suite including XClarity Administrator
* Optional lockable front bezel


* XClarity Controller with upgrades
* Full XClarity software suite including XClarity Administrator
* Optional lockable front bezel
* Optional intrusion switch
* Support for External Diagnostics Handset
* Platform Firmware Resiliency (PFR) hardware Root of Trust


Power supplies


* 2x Hot-swap PSUs up to 1100W, Platinum
* 750W Hot-swap Titanium PSU
* -48V DC power for Telco
* 240V HVDC support in China


* 2x Hot-swap PSUs up to 1800W, Platinum
* 750W Hot-swap Titanium PSU
* -48V DC power for Telco
* 240V HVDC support in China





Contact us


zl2014





company information3








Our services


Our Service
1.You can customize the configuration you need
2. Our Pre-sales and After Sales teams have abundant sales experience in both local and overseas market. Professional Technology team will help you solve any problems.
3. Email / Mobile / Skype / Whats app all are 24 hours available since you need.
4. Due to product quality, we will refund the full amount.



Our Strength
1. Configure according to your needs
2. One of market leadersfor hardware and software business in China.
3. ''Quality is our culture'', we guarantee the goods are original.
4.''Time is gold'' is for you and us. We will ship the goods within 3-7 days after payment.
5. We have a professional team to service for you at any time.
6. Provide a good discount for promoting.
7. MOQ: 1!!!
8. Support Advanced deposite, when we prepare the devices, paid the balance
