FEATURES AT A GLANCE


Chinese Hot Selling 200mm Cold Milling Machine XM200(E/K)
Main Features:XM Series milling machine is one of the main asphalt concrete road maintenance equipment, mainly used for large-scale highways, urban roads, airports, freight yard, etc for renovation of asphalt pavement. One-time removal of entire concrete overlay. It can also be used for cleaning protuberance, oil layers, retieulation and vehicle tracks as well as road trench, tunnel excavation. cement road surface roughening and dislocation smothness.
The equipment features advanced performance, high efficiency, simple process, easy control of milling depth, flexible operation, good maneuverability and the old material recycling and utilization. It is an ideal equipment for pavement maintenance and renovation.

Performance and characteristic
* Hydraulic driving milling drum has the obvious characteristics of stable milling and high efficiency.
* Three-wheeled full driving moving system and the hydraulic differential lock can ensure to be suitable for the poor road conditions with stepless transmission and highlow shift gears,to meet the fast transfer and milling operation requirement .
* The steering of the single front wheel ,with small turning radius ,can mill along the manhole covers.
* The high-strength and high wear resistance imported cutter head and cutter rest have long service life and low construction cost.
* The imported hydraulic parts and reducers have high working reliability.
* Excellent welting milling performance with right rear leg which can be fast swung into the frame makes the milling drum attached to the road edge stone or wall for milling operation.
* Hydraulic handheld breakers and rumble strip equipment can be selected.


PRODUCT SPECIFICATIONS


Description
Unit
Parameter value
Milling width
mm
2000
Milling depth
mm
320
Cutter spacing
mm
15
Diameter ofrotor (Including cutter)
mm
980
Manufacturer
Weichai
Cooling type
Water cooling
Model
DHP13
Rated power
KW
396
Emission standard
China-III
Maximum working speed
m/min
0-40
Fuel tank
L
1400
Hydraulic oil tank
L
400
Water tank
L
3400
Machine dimensions (L×W×H)
mm
14200*2500*4900mm
Maximum working mass
kg
31000kg
travel speed
km/h
0~5km/h


Power


Engine
Model
Power/rotation speed
Emission standard
Transmission
Model
Gear
Drive axle
Model
