Cheap Sale Multifunctional Four Wheel Loader Safe Steering Skid Steer Loader Can Be Customized
- Category: >>>
- Supplier: Yimei Machinery Equipment Manufacturing Co. Ltd.Yimei Ltd.
Share on (1601322444775):
Product Overview
Description
Welcome To Yimei Machinery Equipment Manufacturing Co.Ltd
This price is the deposit price for product production
We adhere to the business philosophy of customer first, all products have been strictly inspected before leaving the factory to ensure that they meet the highest safety standards, we believe you will be very satisfied with its quality after receiving the goods. If you don't find the product you need, you can tell us, we will provide diverse styles for you to choose, please feel free to buy! Thanks again.
Company Profile
Product Description
Wheel Sliding loader is a wheeled specialized chassis equipment that utilizes the difference in linear speed between the two sides of the wheels to achieve vehicle steering. Mainly used in situations where the work site is narrow, the ground is uneven, and the work content changes frequently.
Suitable for infrastructure construction, industrial applications, dock loading and unloading, urban streets, residential buildings, barns, livestock sheds, airport runways, etc., it can also be used as auxiliary equipment for large-scale construction machinery. There are two types of walking modes for sliding loaders: wheel type and track type.zmwm24
Suitable for infrastructure construction, industrial applications, dock loading and unloading, urban streets, residential buildings, barns, livestock sheds, airport runways, etc., it can also be used as auxiliary equipment for large-scale construction machinery. There are two types of walking modes for sliding loaders: wheel type and track type.zmwm24
Product Paramenters
Rated load | Kg | 890 | ||||
Overturning load | Kg | ≥1780 | ||||
Operation quality | Kg | 2880±3％ | ||||
Max. traction force | KN | ≥25 | ||||
Max.excavation force | KN | ≥25 | ||||
Max.lifting force | Kg | 1780 | ||||
Engine | model | —— | Cummins HFC4DA1-2C3 | |||
Rated power | KW | 36.8 | ||||
Rated speed | rpm | 2200 | ||||
Cooling method | —— | water-cooling | ||||
emission standard | —— | National Ⅲ | ||||
performance parameter | Operation method | —— | Pilot hydraulic control&multifunctional electronic control | |||
Tire standards | —— | 10-10.5 | ||||
Maximum speed | Km/h | 12 | ||||
hydraulic system | flow | L/min | 55 | |||
pressure | Mpa | 21 | ||||
shape parameter | A | Max. operating height | mm | 3790 | ||
B | Bucket pin height | mm | 3020 | |||
C | Roof height of the cab | mm | 2095±5％ | |||
D | Horizontal length of bucket ground | mm | 3450±5％ | |||
E | Horizontal length of bucket pin | mm | 2700±5％ | |||
F | Tail length | mm | 1160±5％ | |||
G | wheelbase | mm | 1079 | |||
H | Ground clearance | mm | 185±2％ | |||
I | Departure angle | mm | 22±2 | |||
J | Maximum horizontal distance at the bottom of the bucket | mm | 2846±5％ | |||
K | Max. unloading height | mm | 2384±5％ | |||
L | Bucket ground retraction angle | mm | 27±2 | |||
M | Unloading distance | mm | 520±1％ | |||
N | Unloading angle | mm | 43±2 | |||
P | width | mm | 1640±2％ | |||
Q | Track width | mm | 1370 | |||
R | Bucket width | mm | 1800±2％ | |||
U | Turning radius before carrying a bucket | mm | 1970±5％ | |||
S | Rear turning radius | mm | 1790 | |||
T | Turning radius without bucket | mm | 1215 | |||
Others | —— | Bucket capacity | m³ | 0.4 | ||
—— | Diesel tank capacity | L | 80 | |||
—— | Hydraulic oil tank capacity | L | 46 | |||
We have a wide range of loader models for you to choose from, you can also send us your requirements, we will provide you with the right loader style, engine and other mechanical original parts, we can also provide you with customized services.
Product Photos
Details Images
Product Video
Why Choose Us
FAQ
Are you the manufacuturer or trade company ?
We are the manufacturer for producing tunnel grilled slag machine,rock mucking loader, mining transport car ,and verious attachments With mining equipment.
And we have owned trading company to do the International Business,
So that :
1)-We can supply good service with professional international trade experience.
2)-The price is much more competitive.
Can you do the ODM or OEM, what is MOQ?
Yes, it is possible as both discussed, MOQ: 1unit.
What about delivery time,how long can I get the machine since order.
The producing time fast to 15-20 workings if you will customerized machine. The standard machine in stock, can delivery as soon as possible after ordering.
How to pay for you ?
30% down payment, then producing start, the balance 70% paid before
shipping.
If the machines in stock, pay 100% then delivery.
