China Famous brand GR100 road grader machine mini motor grader for sale
- Category: >>>
- Supplier: Cruking Engineering Equipment (Xiamen) Co. Ltd.Cruking Ltd.
Share on (1601353692264):
Product Overview
Description
Hot sale china top brand reliable manufacture cheap100hp motor grader GR100 with motor grader parts model
Contact Way
Product Overview
Motor grader GR100 is mainly used for ground leveling, ditching, slope scraping, bulldozing, scarification, snow removal for large areas such as highway, airports, farmlands etc. motor grader GR100 is the necessary construction machinery for national defense construction, mine construction, urban and rural road construction and water conservancy construction, farmland improvement and so on.
The motor grader GR100 is a remarkable piece of construction equipment. It is a medium-sized grader with a total weight of around 7,000 kg. Powered by a turbocharged diesel engine, it offers reliable performance. The forward travel speeds include 5km/h, 10km/h, 20km/h, and 39km/h, while the reverse speeds are 8km/h and 25km/h. It features a blade with a width of 3,048 mm and a height of either 450 mm or 500 mm. The overall dimensions are 6,880 mm in length, 2,375 mm in width, and 3,150 mm in height. This grader is suitable for various ground leveling and grading tasks, such as in road construction and site preparation. Its compact size and efficient operation make it a popular choice among contractors, enabling them to achieve precise grading and leveling results with relative ease and enhancing the overall quality and productivity of construction projects.
Advantages and Highlights:
1. motor grader GR100 adopts Dongfeng 4BTA3.9-C100-II (SO11847) turbocharged diesel engine with large
output torque and power reserve coefficient and low fuel consumption.
output torque and power reserve coefficient and low fuel consumption.
2. The torque converter has a large torque coefficient, a high efficiency, a wide effective area, and a good joint operation characteristic with the engine.
3. The drive axle is a dedicated axle.
4. Rear axle main drive is equipped with "NO-SPIN" without self-locking differential.
5. The service brake is a dual-circuit hydraulic brake system that acts on the two rear wheels of the grader and is safe and reliable. 6. The sealed cab is used to configure the air conditioning system. Fully reflects the needs of ergonom
Contact me
Candice Li
Mobile/WhatsApp/Wechat: +86-13599640301
Email:candice@cruking.com
Candice Li
Mobile/WhatsApp/Wechat: +86-13599640301
Email:candice@cruking.com
Product Paramenters
Item | GR100 |
Engine model | J-XZGR100-4BT3.9 |
Rated power/speed | 75(2400r/min) |
Overall dimension (standard) | 6880X2375X3150 |
Total weight (standard) | 7000kg |
Tire specification | 16/70-24 |
Ground clearance (front axle) | 550mm |
Tread | 1900mm |
Space of front and rear axles | 4885 mm |
Forward velocity | 5,8,11,17,24,38km/h |
Reverse speed | 5,11,24km/h |
Tractive effort f=0.75 | 39.2N |
Maximum gradeability | 20% |
Tire inflation pressure | 300kPa |
Working system pressure | 16MPa |
