Spot Goods Special Price for Sale DONGFENG 4x2 Middle Size Dump Truck Cargo 260hp Euro3 Tipper Trucks
- Category: >>>
- Supplier: Zhejiang Jingyan Technology Co. Ltd.Zhejiang Ltd.
Share on (1601354450926):
Product Overview
Description
Products Show
Vehicle parameters | ||
Vehicle Model | EQ3182E | |
Overall dimensions | 7000X2500X2700mm | |
Curb weight | 6505kg | |
Van dimensions | 4200X2300X1000mm | |
Loading capacity | 15tons | |
Chassis parameters | ||
Chassis model | EQ5182GLJ | |
Chassis brand | DONGFENG | |
Overall dimensions | 6700x2350x2550mm | |
Wheel base | 3800mm | |
Front/rear wheel track | 1745/1630mm | |
Front/rear suspension | 1130/1795mm | |
Approach/departure angle | 25/18 | |
Maximum speed | 88km/h | |
Chassis Manufacturer | Dongfeng Motor Company | |
Cab | ||
Configuration | Dongfeng JIANJIN cab, a row and a half deluxe cab(with sleeping berth),allowable 3 passengers | |
Color | White,other color is optional | |
Engine | ||
Model | C260 33 | |
Emission | Euro 3 | |
Type | 6 cylinders, in-line,diesel engine | |
Rated power | 260hp | |
Displacement | 8300ml | |
Max.torque | 1090N.m | |
Manufacturer | Dongfeng Cummins Engine Co.,Ltd | |
Tire | ||
Size | 11.00R20 steel wire tire | |
Number | 6+1 nos | |
Brake | exhaust brake | |
Front axle | 6.5T | |
Rear axle | 16.0T | |
Drive form | 4X4 | |
Rated voltage | 24V,DC | |
Transmissions | Fast 10JS120 | |
Steering device | Power assisted steering | |
Steering wheel | Left hand drive | |
If there is a slight change in the chassis parameters above,please take the actual product as the standard | ||
Dump truck structure parameters | ||
Van body dimensions | 4200X2300X1000mm | |
Side wall | 4mm | |
Bottom plate | 5mm | |
Van body material | Common steel | |
Lifting position | Front | |
Dumping direction | Rear | |
Oil Cylinder | Domestic | |
Color and Logo | Optional | |
Standard configuration | chassis,sub frame,van body side 4mm bottom 5mm,domestic front lifting hydraulic cylinder,common steel,two longitudinal beams,rectangular van body,single door | |
Certifications
Packing & Shipping
Why Choose Us
Payment & Delivery
FAQ
Q1. What is your terms of packing?
A: Generally, our cargo is suitable for naked or waxed packing, in container or bulk ship or RO-RO ship according to the size of the cargo.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery.
We'll show you the photos of the products and packages before you pay the balance.
We'll show you the photos of the products and packages before you pay the balance.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A: Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q6. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the
courier cost.
courier cost.
Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
Q8: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
