16 channel dvr cctv camera kit Vehicle AI Box 1080P Mobile DVR truck dvr video recorder system 4G GPS WiFi
- Category: >>>
- Supplier: Xiamen Lenz Communication Co. Ltd.Xiamen Ltd.
Share on (1601356086036):
Product Overview
Description
Technical Specification
Item | Technical Specification | ||
System | CPU Processor | ARM Cortex A53 | |
Operation System | Linux | ||
Network | WAN | 3G, 4G LTE | |
Wi-Fi | IEEE 802.11b/g/n/ac | ||
GPS | Cold Start | <35 s | |
Hot Start | <2 s | ||
GPS Mode | GPS/Beidou | ||
Accuracy | ≤ 5 meters | ||
Tracking Sensitivity | -159dBm | ||
Video | Video Input | 16 channels, 720P/1080P AHD | |
IP Camera | 2 channels, 720P/1080P IPC | ||
Video Output | 1 channel | ||
Video Encoder | Dual-Steam Video Encoder | ||
Video Compression | H.264/H.265 | ||
Frame Rate | 1-25 fps | ||
Audio | Audio Input | 10 channels | |
Audio Output | 1 channel | ||
Audio Compression | ADPCM | ||
Storage | HDD/SSD | 2*HDD/SSD, SATA 2.5 | |
SD Card | 1*SD | ||
Disaster Backup | Support 1 disaster backup unit | ||
Ports | Sensor I/O | 8 channels in, 2 channels out | |
RS232 | 3 channels | ||
RS485 | 2 channels | ||
CAN Bus | 2 channels | ||
USB | 1 channel, USB 2.0, type A | ||
SD | 1 SD Card Slot | ||
SIM Card | Standard SIM Card | ||
Power Supply | Power Input | DC 9V ~ 36V | |
Power Output | 5V@500mA | ||
Power Output(AHD) | 16CH 12V@500mA | ||
Power Output(IPC) | 8CH 12V@500mA | ||
Power Consumption | <25W (not connect with accessories and HDD) | ||
Environment | Working Temperature | -20°C ~ +70°C | |
Storage Temperature | -45°C ~ +85°C | ||
Others | Dimension | L 188*W 213*H 112 mm | |
Net Weight | ≤1.88 kg | ||
Certificate | CCC, CE, RoHS, Emark | ||
Management System
The Fleet Management System will be provided to users for tracking location of vehicles, check the event happens in vehicle and upload the video remotely. It has below features:
1. Provide the live video streaming to users by both mobile application and website.
2. User could upload or download the video from the MDVR remotely.
3. User could set up the video uploading plan.
4. The panic alarm will activate an uploading of video to control centre.
5. The user could set up the limitation to use the 4G data.
6. The device maintainer could upgrade the MDVR program remotely.
1. Provide the live video streaming to users by both mobile application and website.
2. User could upload or download the video from the MDVR remotely.
3. User could set up the video uploading plan.
4. The panic alarm will activate an uploading of video to control centre.
5. The user could set up the limitation to use the 4G data.
6. The device maintainer could upgrade the MDVR program remotely.
