Item | Unit | XL2103 |
Mixing width | mm | 2100 |
Max. milling depth | mm | 0~400 |
Rotor diameter | mm | 1280 |
Min. turning radius | mm | 7100 |
Rated power | kw | 294 |
Rated speed | rpm | 1900 |
Max. fuel consumption rate | g/kW.h | 207.6 |
Working speed | km/h | 0~3 |
Travelling speed | km/h | 0~23 |
Theoretical gradeability (working gear) | % | 20 |
Ground clearance | mm | 450 |
Fuel tank | L | 450 |
Hydraulic oil tank | L | 450 |
Machine mass | kg | 15600 |
Front axle mass | kg | 3200 |
Rear axle mass | kg | 12300 |
Mechanical (length x width x height) | mm | 8740*2765*3450 |
