High Efficiency 500KW CHP Gas Genset In Gas Turbine Generators

GAS GENSET DATA

Genset model

KDGH500-NG

Prime power (kW/kVA)

500/625

Connection type

3 phases 4 wires

Power factor cosfi

0.8 lagging

Voltage(V)

220/127

Frequency (Hz)

60

Rated current(Amps)

1640

Voltage Stabilized regulation

≤±1.5%

Voltage Instantaneous regulation

≤±20%

Voltage Recovery time (s)

≤1

Voltage Fluctuation ratio

≤1%

Voltage Wave aberration ratio

≤5%

Frequency Stabilized regulation

≤1%(adjustable)

Frequency Instantaneous regulation

-10%~12%

Frequency Fluctuation ratio

≤1%

Net weight(kg)

4400

Genset dimension (mm)

4400X2010X2450

 Engine Data

Model

HGKT38

Type

4 stroke, water-cooling, wet cylinder liner, electronic-control ignition system, pre-mixed perfect mixed burning

Engine output

570kW

Cylinders& Arrangement

12, V type

Bore X Stroke(mm)

159X159

Displacement(L)

37.8

Compression ratio

11:1

Speed

1800RPM

Aspiration

Turbocharged

Cooling Method

Cogen/Water cooled by radiator

Carburetor/gas mixer

Manual control(standard)/

Automatic control (option)

Ignition controller

Altronic CD1 unit

Firing order

1-12-5-8-3-10-6-7-2-11-4-9

Governor type(speed regulating type)

Electronic governing, Huegli Tech

butterfly valve

MOTORTECH

Starting method

Electric, 24 V motor

Idling speed(r/min)

900

Gas consumption(m³/kWh)

0.3 maximal

Oil recommended

SAE 15W-40 CF4 or above

Oil consumption

≤0.5 g/kW.h
