banbury mixer/internal mixer

Product Overview

Description

Model	100L	90L	75L
Mixing Capacity	100L	90L	75L
Productivity (KG/hour)	1400	1200	1000
Driving Motor	300HP/350HP	250HP/300HP	200HP/250HP
Diameter of cylinder	350mm	300mm	280mm
Temperature Difference	±5°C	±5°C	±5°C
Speed of Front Rotor	35rpm	35rpm	35rpm
Speed of Rear Rotor	30rpm	30rpm	30rpm
Weight	23000kg	19000kg	17000kg

prupose:used in rubber,plastic molding and mixing,especially suitable for the tyres,ruuber sole,mixing rubber,synthetic rubber,wire and cable and other industires use

features:the machine rotor and mixing chamber adopts high quality special steel,and all welding carbide wear-resisting,corrosion resistance,resistance to wear,mixing chamber with double input ,transmission torque,smooth operation,high mixing quality,discharge whereabouts for hydraulic pressure type structure,quick speed,transmission power is big ,smooth and durable,mixing chamber adopts unigue sealing structure,effectively prevent raw materail leakage,easy maintenance,use a longtime,the machine fully enclosed mixing ,less dust ,short mixing time(about4 miuntes,faster than pressure type mixer 2-3times)
