HRB PACK цепной Фидер 3 цветный гофрированный картон пакет производство машина с флексографской печати пазов
- Category: Flexographic Printers >>>
- Supplier: Dongguang Hairuibao Carton Machinery Co. Ltd.
Share on (1829352453):
Product Overview
Description
Specification Table
| Modle | 920 | 1224 | 1424 |
| Max.machine speed(pcs/m) | 60 | 60 | 60 |
| Max.feeding size(m/m) | 900x 2200 | 1200x2400 | 1400 x 2400 |
| Min.feeding size(m/m) | 280x 680 | 350x 680 | 420x 680 |
| Max.Depth of slotting(m/m) | 230 | 300 | 410 |
| Die cutting precision(m/m) | ≤±1.5 | ||
| Registration precision(m/m) | ≤±0.4 (four colour) colour) | ≤±0.5(four colour) colour) | |
| Printing plate thickness(m/m) | 7.2 | ||
| Max.printing area(m/m) | 2.5-12(10 Die cutting) | ||
| Minslotting interval(m/m) | Normal | 160x160x160x160 | |
| Reverse | 300x60x300x60 | ||
Product Description
1.Gear enclosed spray lubrication system, keyless drive design, so that accurate long-term chromatic unchanged. High Speed Flexo Printing Slotting(stacking Unit).
2.Phase institutions is 360-degree Electric adjustment, ergonomic design.
3.Four-blade sync adjustment for carton height.
4.Serrated slotted cutter. Thickness: 7mm.
5.Slotter and creaser combined movement.
1.Rubber roller mechanical spiral commutation 40mm move about horizontal structure.
2.Die-cutter phase, computer and electric digital control.
3.Horizontal phase, computer and electric digital control, range ±5mm.
4.Rubber roller and die roller gap use computer and electric digital control.
5.Adjust the transfer roller use computer and electric digital control.
6.The rubber roller compensated by motor-driven,control the speed of thr rubber roller, range ±3mm.
1.High precision bevel gear, adopt 20CrMnTi quality steel, carburizing quenching, fine grinded gear, transmission gear of high strength, good wear resistance, low noise, longtime ensure the machine rotation precision.
2.Lubrication adopt closed type spray lubrication system, to ensure transmission accuracy and use-life.
1.Gear enclosed spray lubrication system, keyless drive design, so that accurate long-term chromatic unchanged. High-speed Ink Printing Slotting Machine Manufacture.
2.Frequency control system to control becomes easy and flexible. Each group of printing unit is equipped with jogging button for easy control and loaded rubber plate.
3.Each printing unit can be electrical separation. Printing Slotting Machine.
4. High-precision anilox roller, diameter 195mm. The textured density of anilox roller is 180-300 lines / inch, to ensure the printing effect is clear and beautiful.
5.Ink supply system is pneumatic diaphragm pumps, high efficiency, Flexo Printing Slotting Machine. saving ink. Automatic cycle supply. Cleaning with clean water can be
6.Automatic uniform system to keep the anilox roller quit. When the machine stop, the anilox roller and rubber roller could running independently for transmission ink and prevent the ink dry out.
7.The rubber roller is use high quality hard wearing rubber,and with the middle of a relatively high high-precision grinding. Semi Automatic Carton Flexo Printing Slotting Machine.
8.Phase institutions is 360-degree Electric adjustment, ergonomic design.
