This machine is horizontal PVC heat shrinkable film blowing machine for making PVC heat shrinkable film, PVC shrinkable film is widely used for making printing labels, packing film. etc.
FEATURE
1. Horizontal type extruding machine, easy operation and very suitable for small size film roll making.
2. Adopts all frequency inverter to control main motor, traction motor and rewinding motor, high efficient and save energy.
3. Material of screw: high quality 38CrMoAlA after 45 days nitrogen treatment, supplied from Zhoushan city.
4. Gear box: hard teeth gear surface, casting alloy piston, high precise grinding, with coolant, supplied by Shuguang®, Xiaoshan city.
5. Die mold adopt 40Cr mold steel, hard chrome-plating.
6. All electric apparatus adopts famous brand CHINT® wenzhou city.
7. Second inflation adopts stainless steel water tank.
8. With two pieces water size rings as standard configuration.
9. Digital intelligent temperature controllers, automatic temperature control
MODEL
Model
SJ-40H
SJ-45H
SJ-50H
SJ-55H
SJ-60H
Film width range
22-120mm
40-300mm
80-400mm
100-500mm
250-600
Film thickness range
0.01-0.08mm
0.01-0.09mm
0.01-0.10mm
0.01-0.12mm
0.01-0.15mm
Output
170kg/day
10-30kg/h
15-40kg/h
20-50kg/h
40-60kg/h
Screw diameter
¢40mm
¢45mm
¢50mm
¢55mm
¢60mm
Screw ratio
26:1
28:1
28:1
28:1
28:1
Main motor power
7.5kw
11kw
11kw
15kw
18.5kw
Main heating power
7kw
9kw
11kw
12kw
14kw
Die head diameter
¢10
¢30
¢50
¢80
¢100
Machine weight
1.8T
2T
2.2T
2.5T
2.8T
Power input
380V, 50Hz, 3P
380V, 50Hz, 3P
380V, 50Hz, 3P
380V, 50Hz, 3P
380V, 50Hz, 3P
Machine dimension
8.5*0.8*1.5
8.7*1.0*1.5
8.8*1.1*1.6
9.0*1.2*1.6
9.5*1.3*1.6
Packaging & Shipping
Our Services
1. Professional manufactory 2. Fast response, within 24hrs 3. Overseas service avaliable 4. OEM service 5. Common model machine, fast supply, within one week. 6. Technicial support after the machine order. 7. Accept trade assurance, T/T, L/C, Western Union as payment. 8. Video avaliable at: https://www.youtube.com/channel/UCRj4rAPNebaiJvfSAm_XLNw
Company Information
Rui'an Zhonglong machinery factory is professional, large and high standard manufactory of series plastic packing machines in China. Our company was established in Year 1997, we have long history, reliable credit, and good technologies, within the years development, we also got several China national patents for plastic packing machines.
Our company professionally produce following equipment: 1.Plastic film blowing machine, like PE one and multi-layers film blowing machine, PP film blowing machine, PVC shrink film blowing machine, POF film blowing machine. 2.Bag making machines for T-shirt bags, Flat bags, Non-woven bags, Drawstring bags. 3.Printing machines: Rotogravure printng machine and flexo printing machine. 4.Plastic recycling machines like plastic granulator, plastic crusher, plastic agglomerator. 5.Plastic disposable cup making line, including sheet extruder, thermo forming machine and etc.
We welcome customers from local market and all over the world to visit our factory to inspect our ability and order machines from us. We will always to supply our machines with best prices and high standard.
Thanks for visiting our website.
FAQ
Q. Are we manufactory of trade company? A. We are factory has big workshop space and long history.
Q. What kind machines we produce? A. Our factory produce plastic machines, we have plastic film extruder, bag making machine, and plastic bag printing machine, plastic recycling machine, etc.
Q. What kind payment we accept? A. Payment term like T/T, L/C, Western union, are all ok.
Q. Can we produce the machine as customer costom order? A. Yes.
Q. Can customer send worker here to study the operation of the machine? A. Yes.
Q. Can customer send technician here to inspect the machine and loading? A. We welcome you to visit us for this purpose.
Q. Can we send technician abroad to install the machine and train the workers? A. Yes. we can send technician by the order of customer.
Q. How long we need to produce the machines? A. According to different machine model and configuation, we need different time, like 5 days to 2 months.
