2 Ton Manual Hydraulic Stacker With Adjustable Forks For Sale
US $270.00-$550.00
Алюминиевая ручная Рабочая платформа для подъема воздушной лебедки
- Category: Stacker & Reclaimer >>>
- Supplier: Nu-Lift Equipment Co. Limited
Share on (1848823340):
Product Overview
Description
Forks up is for supporting, Forks down is for loading goods.
Lifting height Max. 7.9 meters
Designed specifically for the construction industry.
These heavy-duty units can be operated by one person and can lift, lower and move.
Glide rails allow one person to easily load or unload the unit, as well as lift it in or out of a pickup truck.
Model | LGA10 | LGA15 | LGA20 | LGA25 | ||
Capacity(kg) | Load Center | 40cm | 350 | 350 | 250 | 200 |
60cm | 350 | 350 | 200 | 150 | ||
80cm | 250 | 250 | 150 | 100 | ||
100cm | 150 | 150 | 100 | 75 | ||
Max working height(m) | 3.5 | 5 | 6.5 | 7.9 | ||
Height-stowed A(m) | 2 | 2 | 2 | 2 | ||
Length-stowed B(m) | 0.75 | 0.75 | 0.75 | 0.75 | ||
Length-operating C(m) | 1.5 | 1.88 | 2.08 | 2.08 | ||
Width-straddle min | D(m) | 0.75 | 0.75 | 0.75 | 0.75 | |
Width-straddle max | 1.88 | 1.88 | ||||
Load height-min Em | 0.15 | 0.15 | 0.15 | 0.15 | ||
Ground clearance Fm | 0.05 | 0.05 | 0.05 | 0.05 | ||
Net weight kgs | 120 | 145 | 185 | 205 | ||
