PLASTAR 1500mm Plastic Abc 3-Layer Film Blowing Machine
US $110000-$120000
High Speed Automatic Roll changing Plastic PE film blown extrusion machine price for plastic bag making
- Category: Blown Film Production Line >>>
- Supplier: Ruian Zhonglong Plastic Machinery Co. Ltd.
Share on (1872402940):
Product Overview
Description
High speed plastic film blowing machine, nylon bag film blowing machine
USAGE
High speed PE plastic film blowing machine, for HDPE, LDPE, MDPE, LLDPE, etc.
Kinds of film are widely used for packing liquid, industrial products, garments and textile; for making plastic bags, like T-shirt bag, flat bags, garbage bags etc.
OPTIONAL DEVICE
1. PLC full automatic roll change winder
2. Automatic material feeding
3. Traction up and down lifting
4. Hydraulic filter changer system
5. Corona treatment
6. Double stations winder
Model | SJ-50H | SJ-55H | SJ-60H | SJ-65H | SJ-75H |
Film Width | 50-600mm | 80-800mm | 300-1000mm | 400-1200mm | 500-1500mm |
Main Output | 60-70kg/h | 80-100kg/h | 100-120kg/h | 110-130kg/h | 160-200kg/h |
Main motor power | 15kw | 18.5KW-22kw | 30kw | 30kw | 45kw |
Screw Diameter | 50mm | 55mm | 60mm | 65mm | 75mm |
L/D ratio of screw | 32:1 | 32:1 | 32:1 | 32:1 | 32:1 |
Speed of screw | 150r/min | 150r/min | 150r/min | 150r/min | 150r/min |
Film thickness | 0.005-0.10mm | 0.005-0.10mm | 0.005-0.10mm | 0.005-0.10mm | 0.01-0.15mm |
Die head size | 60-120mm | 100-170mm | 120-200mm | 120-200mm | 350mm |
Weight of machine | 2200kg | 2500kg | 3300kg | 3500kg | 5000kg |
Overall Dimension | 4.8*1.8*4.1m | 5.5*2.0*4.2m | 6.5*2.2*5.2m | 6.7*2.4*5.5m | 7.5*2.7*6.0m |
