Small Size BOPP Adhesive Tape Printing Machine

Product Overview

Description

Small Size BOPP Adhesive Tape Printing Machine





 Use:
Small Size BOPP Adhesive Tape Printing Machine is suitable for roll materials printing, such as various paper, film(BOPP,OPP,PP,PE,PET), self-adheive labels, nonwoven, pp woven sack, foil, etc.

 Characteristics:
 1. Easy operation, flexible starting, accurate colour register.
 2. The meter counter can set printing quantity according to the requirements. Stop the machine automatically at the set quantity or when the material is cut off.
 3. Lift and lower the printing plate cylinder manually, it will automatically stir the printing ink after lifting.
 4. The printing ink is spread by the knurled cylinder with even ink colour.
 5. Reliable drying system coordinated with high-speed rotation, it will automatically break circuit when the machine stops.
 6.3600 continuous and adjustable longitudinal register device.
 7. The imported frequency control of motor speed adapts to different printing speeds.
 8. There are inching/stopping buttons on the plate roller base and material rolling rack so as to make it easy operate the machine when the plate is installed.



Main Technical Variables:
Model of Machine	YT-2600	YT-2800	YT-21000
Max. Width of PrintingMaterial	600mm	800mm	1000mm
Max. Printing Width	560mm	760mm	960mm
Length Range of Printed  Product(mm)	180-1200	180-1200	180-1200
Max. Diameter of Roll Material	Φ 450mm	Φ 450mm	Φ 450mm
Printing Speed	5-50m/min	5-50m/min	5-50m/min
Thickness of plate(Including  Two-sided Glue Paper)	2.38mm	2.38mm	2.38mm
Total Power	10.87kw	12.5kw	14.37kw
Weight of Machine	3000kg	3500kg	4000kg
Overall(mm)Dimensions	2200X1600X2400	2200X1800X2400	2200X2000X2400
