worm gearboxes series QY reducer

Product Overview

Description

worm gearboxes series QY reducer

Detailed Product Description

worm gearboxes series QY

speed reducer, speed reducers, worm reducers, worm reducer, worm gearbox, worm gearboxes

SIZE	RATIO	A	A1	AB	AC	B	BB	BD	BE	BF	CC	H	NEMA Frame
133	5:1 10:1 15:1 20:1 30:1 40:1 50:1 60:1	2.12		3.96	4.00	6.03	4.00	2.88	2.00	3.25	1.333	4.66	56C
154		2.75		4.50	5.13	6.76	4.31	3.69	2.75	4.19	1.540	5.38	56C
175		2.75		4.37	4.81	6.75	4.31	3.38	2.75	4.19	1.750	5.75	56C
206		3.00		4.76	5.50	7.25	4.69	3.75	2.88	5.00	2.062	6.38	56C
237		3.56		5.10	6.13	7.78	5.08	4.06	2.88	5.00	2.375	6.94	56C   140TC
262		3.69		5.69	7.12	8.50	5.63	4.44	3.38	6.38	2.625	8.00	56C   140TC   180TC
300		4.50	5.93	5.67	8.50	10.25	6.75	5.50	4.00	7.00	3.000	8.88	56C   140TC
				6.45									180TC
325		4.50	5.93	5.69	8.50	10.50	7.06	5.00	4.00	7.50	3.250	9.38	56C   140TC
				6.47									180TC
375		5.75	7.42	6.01	9.50	11.88	7.75	6.38	4.75	8.50	3.750	10.44	56C   140TC
				6.79									180TC   210TC
450		5.63	8.11	6.69	10.88	13.16	8.44	7.38	5.81	9.56	4.500	11.94	140TC
				7.47									180TC   210TC
516		6.44	8.92	8.28	12.50	13.91	9.06	7.38	5.81	11.00	5.167	13.75	180TC   210TC
600		7.44	10.70	9.68	14.50	15.31	10.00	8.13	6.38	12.75	6.000	16.50	180TC   210TC
