IW series Iron worker
- Category: Other Machine Tool Equipment >>>
- Supplier: Shanghai Zhong Jing Imp. & Exp. Corporation
Share on (285756716):
Product Overview
Description
IW series Iron Worker
Feature:
1.With two control pedals, it can be operated separately at the same time without interference
2.The functions are available for punching, notching, flat shearing, angle shearing, bar shearing etc.
Description for Model:
-IW series is standard model, without auto cutting device and coolant system
-IW E is intelligence type, with auto cutting function, temperature control system.Punching and shearing work
separately
-IW L is high effienct double linkage type, with auto cutting, temperature control system. Punching and shearing work together at same time.
Specification:
No. | Item | Unit | IW-60/L | IW-90E/L | IW-120E/L | IW-160E/L | IW-200E/L | |
1 | shearing plate | Angle of shear | ° | 7° | 8° | 8° | 8° | 8° |
Max.shearing thickness | mm | 16 | 20 | 25 | 30 | 35 | ||
Flat bar | (W×T) mm | 250x16 | 330×20 | 330×25 | 355×30 | 400×35 | ||
400x8 | 480×10 | 600×16 | 600×20 | 700×25 | ||||
2 | shearing bar | Round steel | Mm | 45 | 50 | 60 | 65 | 70 |
Square bar | Mm | 40x40 | 45×45 | 50×50 | 55×55 | 60×60 | ||
90°shearing of equal-angle bar | Mm | 120x120x12 | 140×140×12 | 160×160×14 | 180×180×16 | 200×200×18 | ||
45°shearing of equal-angle bar | Mm | 70x70x8 | 70×70×10 | 80×80×7 | 80×80×10 | 80×80×10 | ||
90°shearing of T-bar | Mm | 120x60x12 | 140×70×12 | 160×80×14 | 180×90×16 |
| ||
I beam steel | Mm | 126×74×5 | 160×86×6 | 200×102×9 | 280×124×10.5 | 300×126×11 | ||
channel steel | mm | 126x53x5.5 | 160×60×6.5 | 200×75×9 | 280×86×11.5 | 300x80x11.5 | ||
3 | Notch | thickness | mm | 8 | 10 | 12 | 16 | 16 |
width | mm | 57 | 80 | 80 | 60 | 100 | ||
depth | mm | 100 | 100 | 100 | 100 | 105 | ||
4 | punching hole | Max.punching thickness | mm | 16 | 20 | 25 | 26 | 35 |
Max.diameter of punching | mm | 25 | 30 | 35 | 38 | 40 | ||
Punching force | Ton | 60 | 90 | 120 | 160 | 200 | ||
Depth of throat | mm | 300 | 355 | 400 | 600 | 560 | ||
Max.length of cylinder stroke | mm | 80 | 80 | 80 | 80 | 100 | ||
Number of stroke | times/min | 6 | 8 | 8 | 8 | 8 | ||
5 | Material strength | N/mm2 | ≤450 | ≤450 | ≤450 | ≤450 | ≤450 | |
6 | Motor power | KW | 4 | 5.5 | 7.5 | 11 | 15 | |
7 | Overall dimensions | (L×W×H) mm | 1650x800x1780 | 1950×900×1930 | 2350×980×2100 | 2680×1060×2380 | 2800x1260x2420 | |
8 | Gross weight | KG | 1800 | 2600 | 4800 | 6800 | 9200 | |
