PLASTAR 1500mm Plastic Abc 3-Layer Film Blowing Machine
US $110000-$120000
Latest Downward Water cooled PP Film Blown Machine
- Category: Blown Film Production Line >>>
- Supplier: Donglong Plastic Machinery Co. Ltd.
Share on (453062200):
Product Overview
Description
XSJ-L Series Lower Water-cooled PP Film Blowing Machine/Blown Film Line
Features:
XSJ-L series lower water-cooled film blowing machine employs lower blowing and self-overflowing method to produce products. The produce is features by high transparency, good printing performance and adhesive. The extrusion system of the machine and the plasticization of the machine head have met the international advanced standard. Additionally, there are many types of equipment such as rotary die head, corona treatment and fully-automatic precise temperature control available for your choice. It is the ideal packing material for food, garment and other high grade products.
Main Technical Parameters:
Model No. | XSJ45-FMX500L | XSJ55-FMX800L | XSJ65-FMX1000L |
Layer Number | Single Layer | ||
Max. Folded Film Width | 400mm | 650mm | 800mm |
Film Thickness | 0.02~0.12mm | 0.02~0.12mm | 0.02~0.12mm |
Output | 35kg/h | 50kg/h | 65kg/h |
Raw Material | PP, LDPE, LLDPE | ||
Screw Diameter | Φ45mm | Φ55mm | Φ65mm |
Screw L/D | 28:1 | 28:1 | 25:1 |
Heater Capacity | 8.3kw | 10.7kw | 13.1kw |
Power of Main Motor | 11kw | 18.5kw | 22kw |
Die Diameter | 150mm | 250mm | 400mm |
Die Heater Capacity | 4.5kw | 8kw | 10.5kw |
Cooling Air Blower | 0.55kw | 0.75kw | 0.75kw |
Water Cooling Rings | 10, 12, 15, 17, 20, 25, 30, 32, 35, 40cm | 25, 28, 30, 35, 40, 45, 50, 55, 60, 65cm | 35, 40, 45, 50, 55, 60, 65, 70, 75, 80cm |
Haul-off Driving Motor | 1.5kw | 1.5kw | 1.5kw |
Take-up Speed | 10~55kw | 10~55kw | 10~55kw |
Winder Drive Motor | 2.2kw | 3.3kw | 4.1kw |
Temperature Control | 6 | 7 | 7 |
The Total Power of the Machine | ~28kw | ~45kw | ~55kw |
Shape Size | 4.0*1.3*3.0m | 6.0*1.8*3.6m | 6.7*2.5*4.2m |
Weight | ~2000kg | ~2700kg | ~3500kg |
