6 8 10T Skip Loader Truck

Product Overview

Description

Models  :



SKIP BIN LIFTER LOADER 10 tons



capacity: different types



can transport between 3 cbm skip bin container and 12 cbm skip bin containers.



for more information: please ask us !



.: TECHNICAL SPECIFICATIONS of SKIP LOADER 14 tons

Introduction: Skip loader can transport, load and unload skip containers.

Chassis       : To produce with high quality NPU Profile. Floored 4 mm with figure steel. Mounting parts are U pins.

Guides for smooth placement of container and stoppers for locking in place while moving

Arms          : To produce with 6mm steel. Supporting steels welded around of cyclinder houses. Standart Single Arm Length

Cyclinders  : 2 pieces Main Cyclinders High Quality Cold Drawn pipe and Chrome coated pins. 2 pieces Rear Leg pistons and 1 piece skip container locking piston.

Hydraulic   : 175 bar pump, Entrence hydarulic hose, ½” R2 house wtih fiber on Hyraulic ways.

Valve is European. Main pistons have Twice Security valves.

Accessories: Left and Right Steel ropes at end of arms.
