Cold steel roof door MHV/ MHL Tile Forming Machine Metal Roofing Roll Former Equipment
- Category: >>>
- Supplier: Zhejiang Jinggong Integration Technology Co. Ltd
Share on (522875659):
Product Overview
Description
Equipment Overview-HV (HVM) SERIES ROLL FORMING MACHINE
This is the ideal equipment in the steel structure&cold roll forming industry, the main frame includes double layers and can
produce different profiles. Thas the coccection of mechanic. electric and hydraulic. Therefore it will have high working efficiency and can work full amtomatically.
produce different profiles. Thas the coccection of mechanic. electric and hydraulic. Therefore it will have high working efficiency and can work full amtomatically.
Decoiling ->guiding and feeding ->roll forming ->cut to length-> run out table
Product Description
Item | Parameters | ||||||
Model | HV (HVM) SERIES ROLL FORMING MACHINE | ||||||
Material | Type | Color steel sheet; galvanized sheet,Aluminum sheet | |||||
Thickness(mm) | 0.4-0.8 | ||||||
Yield strength(Mpa) | 230-350 | ||||||
Forming speed (m/min) | 20-30 | ||||||
Roller material | 45#、38CrMoAI或D2 | ||||||
Roller driven type | Chain transmission | ||||||
Control type | PLC | ||||||
Operation type | Touch screen +button | ||||||
Hydraulic system pressure(MPa) | 12 | ||||||
Hydraulic station motor power | 3 OR 5.5 kw | ||||||
Main motor power | Depend on actual design | ||||||
Working process
Guiding system→Roll forming→Punch to length→Cut to length→Output the finished products
Company Profile
FAQ
1.Does one machine can only produce one size?
Not exactly, it depends on the machine.
2.Do you have after sales support?
Yes, we are happy to give advice and also have skilled technicians available to maintain the machine if needed.
3.How to visit your company?
We can pick you up from Shanghai or Hangzhou airport. Or railway station Shaoxing North.
4.What can you do if the machine broken?
Our machine's warranty period is 12months. if the broken parts can't repair, we can send the new parts replace the broken parts, but you need pay the express cost by yourself. if after warranty period, we can through negotiation for solving the problems, and we supply the technical support for the whole life of the equipment.
5.Can you be responsible for transport?
Yes, please tell us the destination port or address. we have rich experience in transport.
6.You are trade company or factory?
We are Manufacturer.
7.Why your price is higher than others?
As we persist on that each factory should put quality at the first place. We spend time and money on developing how to make machines much more automatic, accurate and high quality. We can make sure that our machine could use more than 20 years without any problem.
8.Do you have overseas engineers?
Yes, we not only provide overseas engineers, but also provide technical training.
9.Do you provide customized?
Sure, we can design the equipment according to the data of the structural section you provide. We are professional sheet metal forming machine designer and manufacturer.
Not exactly, it depends on the machine.
2.Do you have after sales support?
Yes, we are happy to give advice and also have skilled technicians available to maintain the machine if needed.
3.How to visit your company?
We can pick you up from Shanghai or Hangzhou airport. Or railway station Shaoxing North.
4.What can you do if the machine broken?
Our machine's warranty period is 12months. if the broken parts can't repair, we can send the new parts replace the broken parts, but you need pay the express cost by yourself. if after warranty period, we can through negotiation for solving the problems, and we supply the technical support for the whole life of the equipment.
5.Can you be responsible for transport?
Yes, please tell us the destination port or address. we have rich experience in transport.
6.You are trade company or factory?
We are Manufacturer.
7.Why your price is higher than others?
As we persist on that each factory should put quality at the first place. We spend time and money on developing how to make machines much more automatic, accurate and high quality. We can make sure that our machine could use more than 20 years without any problem.
8.Do you have overseas engineers?
Yes, we not only provide overseas engineers, but also provide technical training.
9.Do you provide customized?
Sure, we can design the equipment according to the data of the structural section you provide. We are professional sheet metal forming machine designer and manufacturer.
