Plastic t shirt bag printing machine

Product Overview

Description

Two colors flexo printing machine.

flexographic printing machine, flexography printing machine

plastic t-shirt bag printing machine



USAGE
This machine, adopting photosensitive resin as printing plate, is commonly known as the flexographic printing machine. It is suitable for printing packing materials such as polyethylene (PE), polypropylene (PP) bag, nylon, cellophane and roll paper, etc.
It is a kind of ideal printing equipment for producing paper packing bag for food, supermarket handbag, vest bag and clothes bag, etc.



PARAMETER

Model	YT-2600	YT-2800	YT-21000
Max. width of substrate	600mm	800mm	1000mm
Max. printing width	560mm	760mm	960mm
Range of Printing length	191 to 914mm	191 to 914mm	191 to 914mm
Max. diameter of material roller	500mm	500mm	500mm
Printing speed	5to50m/min	5to50m/min	5to50m/min
Plate thickness	2.38mm	2.38mm	2.38mm
Total power (kw)	8	10	16Kw
Machine weight (kg)	1800	2000	2300
outline diameter (m)	2.3*1.8*2.145	2.3*2.06*2.145	2.3*2.206*2.145
