Prepaid Gas Meter/Smart Steel Shell Membrane Gas Meter G1.6/G2.5/G4
US $22.00-$32.00
Share on (60246674615):
Range and Capacities | ||||||||||||||||
G1.6 | G2.5 | G4.0 | G4.0+ | |||||||||||||
Qmin | 0.016 | 0.025 | 0.04 | 0.016 | ||||||||||||
Qn | 1.6 | 2.5 | 4.0 | 1.6/2/5/4.0 | ||||||||||||
Qmax | 2.5 | 4.0 | 6.0 | 6.0 | ||||||||||||
Electrical | ||||||||||||||||
Battery | 6.0V, Alkaline battery/Li-battery | |||||||||||||||
Metrological | ||||||||||||||||
Accuracy | + 3% in range Qmin≤Q<0.1Qmax | |||||||||||||||
+ 1.5% in range 0.1Qmax≤Q≤Qmax | ||||||||||||||||
Pressure Loss | ﹤250Pa | |||||||||||||||
Mechanical | ||||||||||||||||
Environmental Classification | Indoor | |||||||||||||||
Protection Class | IP54 | |||||||||||||||
Medium Temperature | -25~55℃ | |||||||||||||||
Storage Temperature | -30~60℃ | |||||||||||||||
Pressure Range | ≤10kpa | |||||||||||||||
Connection axis spacing | 130mm | |||||||||||||||
Dimension | 220*102*152mm | |||||||||||||||
