EPOXY INJECTION RESIN for injection into concrete, masonry and brickwork

Product Overview

Description

EPOXY INJECTION RESIN for injection into concrete, masonry and brickwork

Introduction:
It is mainly made up by epoxy resin, curing agent and other catalyst, it is a grouting material which has high strength and adhesive strength.



Two component white epoxy grout for potting is a room temperature/heating cured epoxy resin. This kind of two-component epoxy adhesive used for design, protection the high strength or confidential electronic products.

Two component white epoxy grout for potting curing without heating. To 4:1 (weight ratio) completely mixed part A and part B, curing in a certain time, and form protection.

Features:
Low viscosity, without granule, able to be injected into tiny cracks
Flexible after joint ,adopt to the changes of the cracks caused by expansion and contraction
Prevent the cracks from leakage.
High strength, can transfer stress
Range of application:

Reinforce, strengthening and leaking stoppage for:

1. Tunnel, metro and other underground structure;

2. The crack of the girder, pillar and pile;

3. Dam, port, wharf, swimming pool and water tower.

4.Seal of the water pipe and chemical pipeline.

Technical Date:

PERFORMANCE	Index
Viscosity (mPa.s)/20°C	< 100
Initial Setting Time(h)/20°C	> 1
Finale Setting Time(h)/20°C	< 5
Bonding Strength (MPa)	> 3/bonding cement mortar“8”mold(dry)
	> 2/bonding cement mortar“8”mold(wet)
Compression Resist (MPa)	>30/Compressive Deformation 50%
Tensile Strength (MPa)	>5
Elongation At Break (%)	100



Application:
Leakage-proofing and concrete reinforcing grouting for deformation cracks, construction cracks and cracks in the field of Subway, water conservancy project, and some industrial and civil concrete buildings.

Construction method:
Consistent with relevant construction specification.

Storage:
In the shade, 12 months of validity without opening the package.
