Refrigerated Truck parts r404a van monoblock refrigeration unit for bottom freezer refrigerator vehicle small cooling unit
- Category: Other Refrigeration & Heat Exchange Equipment >>>
- Supplier: Zhejiang Boyang Compressor Co. Ltd.
Share on (60418116294):
Product Overview
Description
Description:
HQXD series condensing unit is specially designed for commercial freezing coldstorge showcase, kitchen equipment, refrigeration storeroom, vehicle refrigeration equipment and other refrigeration equipments with the structure of the compact, reducing the cost of installation, etc.
1. Refrigerant: R404A
2. Compressor type: rotary
3. Motor type: rotary
4. Evaporating Temp.: -5°C~-40°C
5. Voltage range: 220-240V~50HZ
Company Information:
Company founded: in 2006
Company size: 33,000 square meters
Building area: 20,000 square meters
Staff: 350~400 numbers
Certification: CCC, CE, RoHS, REACH
Production Capacity: 500,000 units per year
Market share: International market 48.26%, domestic market 51.74%
Refrigerated Truck parts r22 r404a van monoblock refrigeration unit for bottom freezer refrigerator vehicle refrigeration
spare parts for cold room r22 r404a frozen refrigeration unit for van for refrigerators and freezers freezer room
freezer parts R22 R404A monoblock style refrigeration units for trucks for dry ice refrigerator bar cabinet refrigerator
r404a lanhai mini compressor type condensator unit for commercial retail refrigerator island display cooler
r22 r404a freezer compressor air condensing units for commercial refrigerator brands open top island freezer
r404a r22 refrigerating compressor marine condensing unit for supermarket showcase cold condensed milk food coold room
r22 r404a mini refrigeration condensing unit replace condensing unit for Ice Cream Fridge Deep Freezer Mini Freezer
r404a r22 outdoor cold room condenser unit replace carrier condensing unit for chest freezer refrigerator cooler for meat frozen food
refrigerator parts r22 r404a indoor wall mounted refrigeration unit for double door sliding door refrigerator locks
refrigeration parts r22 r404a lbp air cooled condensing units for commercial vegetable refrigerator island display unit
r22 r404a refrigeration compressor water cooled condensing unit for commercial display cake refrigerator showcase
Feature:
Low noise and vibration. In the rotary type, noise and vibration is largely reduced compared with the reciprocating compressor. Therefore noise generated by the unit can be reduced.
High reliability. High reliability is achieved due to high-quality material and high-accuracy parts.
High efficiency. Using high efficiency rotary compressor and motor, energy saving.
Wide Evaporating temperature range. Evaporating Temperature is from -5 degree to -40 degrees.
Low height. The total height of the Horizontal condensing unit is not more than 275mm.
Compressors are able to work continuously under high-temperature condition.
Our Service:
Samples: there's a charge for the sample and shipping cost, but if you have quantity in the future, the sample fee will be deducted from next payment.
Warranty: we have one year warranty for manufacturer.
Technical support: We have professional technical department and R&D centre, if you have any questions, feel free to ask.
Performance paremeters:
| MODEL | HQXD-13KAZQ | HQXD-16KAZQ | HQXD-23KAZQ | HQXD-30KAZQ | HQXD-36KAZQ | HQXD-41KAZQ | ||
| NOMINAL INPUT(W) | 720 | 900 | 1280 | 1500 | 1730 | 2030 | ||
| POWER SUPPLY | SINGLE PHASE: 220V-240V/50Hz | |||||||
| REFRIGERANT MAX.(KG) | R404A(1.2) | R404A(1.5) | R404A(2.0) | R404A(3.0) | R404A(3.0) | R404A(3.5) | ||
| START-UP CURRENT (A) | 20 | 27 | 38 | 42 | 50 | 57 | ||
| MAX. RUNNING CURRENT (A) | 4.0 | 5.0 | 7.0 | 8.5 | 10.0 | 11.5 | ||
| EVAP. TEMP. RANGE (°C) | -40~0 | |||||||
| AMBIENT TEMP. (°C) | -7~43 | |||||||
| COMPRESSOR (MODEL) | QXD-13K | QXD-16K | QXD-23K | QXD-30K | QXD-36K | QXD-41K | ||
| CONDENSER | STYLE | 3ROW 6HOLE | 4ROW 6HOLE | 4ROW 6HOLE | 4ROW 9HOLE | 4ROW 10HOLE | 5ROW 10HOLE | |
| FAN MOTOR | DIAMETER QUANTITY (mm) | Φ300 | Φ300 | Φ300 | Φ350 | Φ400 | Φ400 | |
| AIR FLOW (m3/hr) | 1300 | 1700 | 1700 | 2660 | 3860 | 3860 | ||
| PIPE (mm) | GAS INLET DIAM | Φ12.7(1/2") | Φ15.88(5/8") | |||||
| LIQUID OUTLET | Φ9.53(3/8″) | |||||||
| OUT DIMENSION | LENGTH (mm) | 560 | 560 | 600 | 610 | 655 | 630 | |
| WIDTH (mm) | 470 | 540 | 580 | 590 | 590 | 610 | ||
| HEIGHT (mm) | 355±5 | 355±5 | 365±5 | 485±5 | 535±5 | 535±5 | ||
| WEIGHT(Kg) | 27.9 | 33 | 36.5 | 45.6 | 50 | 53.5 | ||
| CAPACITY | EVAP. TEMP.(°C) | REFRIGERATION CAPACITY: W(Kcal/h) CONDENSING TEMP.:45°C AMBIENT TEMP.:32°C | ||||||
| -40 | 504(433) | 630(542) | 850(731) | 1200(1032) | 1250(1075) | 1423(1224) | ||
| -35 | 654(562) | 820(705) | 1104(949) | 1506(1295) | 1604(1379) | 1828(1572) | ||
| -30 | 807(694) | 950(817) | 1240(1066) | 1803(1551) | 2030(1746) | 2314(1990) | ||
| -25 | 975(839) | 1203(1035) | 1565(1346) | 2200(1892) | 2560(2202) | 2918(2509) | ||
| -20 | 1190(1023) | 1430(1230) | 1890(1625) | 2604(2239) | 3050(2623) | 3480(2993) | ||
| -15 | 1430(1230) | 1705(1466) | 2130(1832) | 2950(2537) | 3500(3010) | 3990(3431) | ||
| -10 | 1790(1539) | 2050(1763) | 2460(2116) | 3560(3062) | 4230(3638) | 4822(4147) | ||
| -5 | 2130(1830) | 2340(2012) | 2827(2431) | 3911(3363) | 5000(4300) | 5720(4919) | ||
| WIRING CAPACITY | LEAKAGE PROTECTOR | RATED CURRENT (A) | 10 | 15 | 20 | 20 | 20 | 20 |
| LEAK CURRENT (MA) | 30 | 30 | 30 | 30 | 30 | 30 | ||
DIAMETER (mm²) | IN 10m | 2.0 | 2.0 | 2.0 | 4.0 | 4.0 | 4.0 | |
| IN 20m | 2.0 | 2.5 | 2.5 | 6.0 | 6.0 | 6.0 | ||
| IN 30m | 2.0 | 2.5 | 2.5 | 6.0 | 6.0 | 6.0 | ||
Application:
Cold room, freezer room, cold storage room
Supermarket refrigerator, cabinet, freezer, showcase
Truck transport refrigeration, mobile cold room, mobile freezer room
Kitchen cook equipments, home cold room, refrigerator
Packing:
Sample order:
Each condensing unit was packaged in one non-fumigated wooden box.
Delivery time: Generally we have samples on stock. We can deliver as soon as receiving the payment.
Large order:
The condensing unit will be packaged in one non-fumigated wooden box. One 20 feet container can load 120 to 150 PCS.
Delivery time: within 30 days after receiving the deposit.
Factory View:
New plant
| Be launched in 2018, floor space of 110 bhou, building area of 40000m², more than 100 employees. With modern standard workshop, advanced intelligent equipment and mature production process, with capable of producing 250,000 condensing units annually. Complete quality and environmental management system has been established. | Compressor extension product design, manufacturing, sales, services, products are widely used in the supermarket refrigerator, logistics cold chain, cold storage, liquid cooling, battery heat management and other different application areas, to provide customers with fixed refrigeration field solutions suppliers. |
Certification:
What we supply:
FAQ:
1. Where is your company located in? Located in Shuguang Road, Lanxi City, Zhejiang Province, China.
2. What's your delivery time? 25days for cargo; 5days for sample after payment or deposit.
3. What's your shipping port? Ningbo or Shanghai Port.
4. What's your MOQ? Could start as sample firstly, to match the application.
5. What's the payment terms? T/T, L/C, BOTH OK.
6. What you supply?
- Horizontal air conditioner compressor, R407C, R410a, 220-240V 50Hz, 115V 60Hz
- BLDC compressor, R134A, DC 12V 24V 48V
- Commercial refrigeration compressor, R22, R404a,220-240V 50Hz, 220V 60Hz, 115V 60Hz
- Condensing unit, R22, R404a, 220-240V 50Hz, 220V 60Hz
7. Could you do the New products R&D service for me? Any products of HVAC & refrigeration, we could do the R&D for you.
