Essential oil distillation & extraction equipment

Product Overview

Description



The compact modular design of the oil distillation & extraction equipment evaporator keeps cost to minimum, without any compromise in the essential performance of rotary evaporation. Digital displays for rotation speed and heating bath temperature allow for optimal control of all distilling processes.



Features of the thermostatic evaporator:
- Built-in vacuum controller, High vacuum performance
- PTFE sealing
- Autolly adjust the ascending or descending of rotary flask
- Digital display and control
- Easy assembling design: to be assembled within 30 minutes.
- Double layer cooling coils for improved condenser performance.
- High quality borosilicate glass 3.3 with excellent physical and chemical properties
- Cost-saving modular design and can be customized by clients’ requirements



General Specification of the lab rotary evaporator:

Model	RE2000	RE2000B	RE2000E	RE3000	RE3000B	RE3000E
Rotary flask	0.5-2	0.5-2	0.5-2	3	3	3
Collection Flask(L)	1	1	1	2	2	2
Evaporating Speed (H2O)	>1.5L/h			>2.5L/h
Motor power(W)	40			60
Rotating speed(rpm)	0-199
Water bath power(KW)	2
Power supply	220V/ 50-60HZ (Optional 110V)
Bath Temp control range	Room Temp. ~ 199°C
Sealing parts	Main PTFE Seal, Oil ring and O ring
Vacuum degree	<133Pa



Attention here:

We are professional chemical and pharmaceutical equipment manufacturer and we can produce customized glass rotary evaporator as per clients’ required specification & quantity and deliver goods within required production time, and  design the best solution for your production or experiment need as well.



Structure demonstration of the rotary evaporator:
