small waste collection truck light garbage compactor refuse disposal vehicle
Product Description
Feture
1,Full hermetical and high strength bin box with good corrosion resistance and environmental protection; 2, Automatic loading garbage ,the doors open on both side of the bin box which makes it very convenient for garbage collection; 3,With dump function and hydraulic operation, very easy to dump the garbage; 4,Mainly used for cities, streets,schools and other garbage collection points, it is new sanitation truck which can avoid secondary pollution
WHAT THE SPECIFICATION OF GARBAGE TRUCK?
General Description
Product Name
small waste collection truck light garbage compactor refuse disposal vehicle
Wheel base (mm)
3300 mm
Overall Dimension(mm)
5850*2000*2300
Driving type
4*2, left hand drive
Gross weight (kg)
4495
Number of Leaf Springs
8/9+5,6/8+4
Curb weight(kg)
3465
Rated loading capacity(Kg)
900, 835(Kg)
Transmission
5 speed forward with 1 reverse manual
Axle number
2
Fuel type
Diesel oil
Braking system
Air-cut braking
Approaching/Departure Angle(°)
19/15(°)
F/R Axle load(kg)
1785/2710
Passengers in cab
2,3
Maximum speed(km/h)
90
Number of Tyres
6 (1 spare piece)
Tyre type
7.00-16
Front/Rear suspension(mm)
1032/1518
Front/Rear track base (mm)
1506/1442
Engine parameters
Engine Brand
Dongfeng Chaoyang
Engine Model
CY4102-C3F
Displacement (L)
3.856 L
Emission Standard
EURO 3
Power (kw/hp)
70/95
Maximum torque
365N/m
Number of cylinders
4
Cylinder spread pattern
In-line
Operation control system
Electrically hydraulic control
Rated rotation(rpm)
3200
Equipment
Refuse Container capacity
5m3
Rubbish Discharging Time
<= 30 s
Loading Circulation Time
12- 30s
Compressed Proportion
1:3 / 1:2
Detailed Images
Company information
Hubei Dali Special Automobile Manufacturing Co., Ltd. is appointed by the Ministry of Industry and Information Technology of China.The company has focused on all kinds of special automobile R&D, manufacturing, sales and service, two special automobile production lines of the company are five series and 300 products, which are municipal engineering truck series, oil field chemical truck series, multi-function rescue fire truck series, sanitation special automobile series, semi-trailer trucks. The company is also the first pressure tank vehicle manufacturing private enterprise which has got the quarantine license from General administration of quality supervision of China.Our trucks have popular in more than 30 countries. And has many years of manufacturing experience and passed the certification ofISO9001, ISO16949, GJB9001 ,CCC, ISO and BV factory audit.
Packaging & Shipping
Shipping by bulk ship or container or RORO ship or as per your requirement
Big size trucks always shipping by RORO or Bulk ship or flat bed container or open top container , small type can shipping by container
Welcome to contact
The above information is just for your reference. We can manufacture the trucks as per your request and we can fulfill all your demands.Should you have any other questions or need any other information, pls feel free to contact Doreen. It would be my great pleasure to be on your service. Pls check my contact information as following:
