SZG Series Double cone industrial vacuum dryer

Product Overview

Description

SZG Series Double cone industrial vacuum dryer

Application



It is suitable for the raw material that need to concentrate,mix and dry at low temperature (for example,biochemistry products In chemical, pharmaceutical and foodstuff indu3ries).Paticular1y It is suitable for the raw materials that are easy to oxidize,volatilize and have strong heat sensitive and toxic and not permitted to destroy its crystal in drying.



Scope of Application

rotating condctor seal seat



rotating conector

hot source



Principle



Let heat source (for example,low pressure steam, Ir heat comduct oil) pass through the sealed jacket. The heat will be transmitted to raw material to be rled through Inner shell; Under driving of power, the tank Is rotated slowly and the raw material Inside It is mixed continuously. The puipose of reinforced drying can e realized.

The ra material exists at the state of vacuum. The drop of steam pressure makes the moisture (solvent) at the surface of raw material become saturation and will evaporate. The solvent will be discharged through vacuum prmp and recovered in tima. The inner moisture (solvent) of raw material wil infiltrate, evaporate and discharge continuously. The three processes are carried out unceasingly and tfi© purpose of drying can be realized within a short time



Features



♦            When oil os used to heat, automatic constant temperature control, for drying biology products and mine, fts temperature

be adjusted from 20-1601) and within ± 2t).

♦            Compared wtth ordinal drier,its heat efficiency will be over 2 times.

♦            The heat is indirect So the raw material can not be polluted. It is in oonfomilty with the requirement of GMP. It is easy in washing and maintenance.

It can be used of operation cs Compared wttf





SZG Series Double  Rotary Vacuum Drier

Flow chart



Example of Installation for rooommeoded technology:







Technical Parameters

Item		Type
Name	Unit	100	200	350	500	750	1000	1500	2000	3000	4500
Total volume	L	100	200	350	500	750	1000	1500	2000	3000	4500
Working volume	L	60	100	175	<250	375	500	760	1000	1500	<2250
Heating area	ms	1.16	1.5	2	2.63	3.5	4.61	5.58	7.5	9.6	13.8
Speed	r.p.m	3-13
Power	Kw	0.75	1.1	1.5	1*5	2	3	3	4	5.5	7.5
Height of rotating frame	mm	1810	1910	2090	2195	2500	2665	2915	3055	3330	4210
Total weight	Kg	550	700	900	1100	1200	1300	1500	2000	3000	4000
Design pressure inside tank	Mpa	-0.1—0.15
Design pressure inside Jacket	Mpa	0.3

Attentions to order



Its heating has three ways i.e.steam,hot water,hot conduction oil.

or the operation temperature of drier in order to choose or provide suitable heat source for you.

♦            When dry viscous raw material, our factory will design special sirring device in the chamber.

♦            The cost of complete equipment should be increased In accordance with the needs.



♦ When orcter please indicate the temperature of raw material to be undertaken
