Spiral classifier is one of beneficiation equipment, based on user requirements, it can be divided into single and double spiral classifier. Depend on specific gravity of solid particles, so different sedimentation velocity in a liquid principle, spiral classifier is a mechanical grading equipment. Feed mill can grind the powder level in the filter, and then use the coarse material spiral piece rotary vane screwed mill feeder to filter out fine material discharged from the overflow tube.
According to the difference in sedimentation rate of mineral particles and mud, the particle sizes of ores with 1.5mm-0.03mm are classified. Waste mud or water for ore sand can be separated from the ores. It’s also usually applied to ore washing, desliming and dehydration and so on.
Advantage
1. Low power cosumption,high classifying efficiency
2. Heavy duty, long workinglife
3. Powerful manual control and electric control lifting device
4. Wide choice of weir height, rigid tank and substructure
Working principle
Different solid granularities have different gravity and thus have different dropping speed. The fine ore granularities floating in the water will overflow and the big ones will sink to the bottom and discharge from the upper part by spiral pushing. It can filter the granularities from the machine and then spin the rough particles to charging part by spiral vane and discharge the fine granularities from the overflow pipe. The base of the machine adopts a channel steel and the body adopts welded steel plate. The water inlet of spiral axle and axle head adopt pig iron cover for wear proofing and long life operation. The lifting equipment has two types, manual control and electric control.
Model
Spiral diameter(mm)
Speed of Spiral(r/min)
Power (kw)
Slope (°)
Power(KW)
Sand Return (t/h)
Overflow (t/h)
FG500
500
8-12.5
6-11
32
12-18
1.1
FG750
750
6-10
11-24
65
12-18
3
FG1000
1000
5-8
25-45
110
12-18
5.5
FG1200
1200
4-6
50-80
155
12-18
7.5
FG1500
1500
4-6
70-115
235
12-18
7.5
FG1800
1800
2.5-6
100-190
310
12-18
11
FG2000
2000
3.6-5.5
160-230
400
12-18
15
The spiral classifier tank is heavy plate with strong structural base. The extra heavy shaft has an improved submerged bearing. The greatest improvements, however, are found in the drive-unit which has been strengthened and improved over all other classifiers. A specially designed classifier reducer eliminates the “over – hang” or cantilevered load normally found where the reducer shaft carries the pinion. The Classifier Reducer has an outboard bearing integral with the reducer base which provides positive alignment of the bevel gears.
