MJ-HZ41FA 6 мм G1/4 POM пищевого материала высокая точность воды расходомер датчик частоты пульса

Share on:

Price:3,00 $ - 4,00 $
Price in USD:Details


Product Overview


Product Description

Water flow sensor consists of a plastic valve body, a water rotor, and a hall-effect sensor.
When water flows through the rotor, rotor rolls. Its speed changes with different rate of flow. The hall-effect sensor outputs the corresponding pulse signal.

Brand Name:   MOJO
Model Number:  MJ-HZ41FA
Material:   POM
Imput diameter:   6mm

Output: G1/4 threads
Flow Core:   Hall sensor for Japan AKE 512
Rating Voltage:  5V
Flow range:  0.15-1.5L/min,0.25-2.5L/min,0.4-4L/min
Flow accuracy:  5%
Flow temperature:  -20~60°
Flow pulse character:  F=76*Q±5%(Q=L/Min)
Dielectric resistance:  >100 Ohm
Wiring:Red for the positive, black for the negative, yellow for the pulse signal

Product Advantage

1.Environmental protection design
2.Food grade POM material
3.Small, practical and high precision
4.Can be arbitrary Angle adjustment

Detailed Images
