Датчик движения с магнитным датчиком для системы подсчета автомобиля
- Category: Other Security & Protection Products >>>
- Supplier: Shenzhen Sunfre Intelligent Technology Co. Ltd.
Share on (60563080838):
Product Overview
Description
Traffic magnetic sensor vehicle detector for car counting system
Vehicle Loop Detector Introduction
SFLP102/103 is used for wherever vehicles have to be detected, for example for monitoring and safe-guarding access ways or for counting vehicles. The output signal can be used for controlling door and gate drive mechanisms, operating barriers, controlling traffic light systems or activating card dispensers in parking lots. SFLP102 has two-way output relays. One is unlimited output when loop is temporarily covered, while the other is multi-mode that can be set by users.
SFLP102 has two-way output relays. One is unlimited output when loop is permanently covered,while the other is multi-mode that can be set by users.
Specifications:
| Item | Single Vehicle Loop Detector SFLP102 | |
| 1 | Operating voltages | 12V AC/DC ±5%; 24V AC/DC ±5%; 110V AC ±10%; 220V AC ±10% (Optional) |
| 2 | Power consumption | <5W |
| 3 | Output | Relay output |
| 4 | Frequency range | 20kHz to 170kHz (4 grades adjustable) |
| 5 | Reaction time | 100 ms |
| 6 | Sensitivity | high, medium, low (adjustable) |
| 7 | Loop inductance | Ideal 80~300µH (include connecting wiring) |
| 8 | Max | Max 50µH~500µH (include connecting wiring) |
| 9 | Loop conn. Wiring | max. 100m, twisted at least 20 times per meter, total resistance <10 Ohm |
| 10 | Operating temp. | -30°C to +70°C |
| 11 | Storage temp. | -40°C to +85°C |
| 12 | Connection | 11-pin socket |
| 13 | Dimensions | 74*36*85 mm (L*W*H) |
| 14 | Net Weight | 270g (including socket) |
| PRODUCT INFORMATION | |
| Item | Single Vehicle Loop Detector SFLP102/103 |
| Model | SFLP102 |
| Brand | Sunfre |
| Size | 74*36*85 mm (L*W*H) |
| Net Weight | 270g (including socket) |
| Usage | Vehicle access detection |
| MOQ | 1 Set |
| ODM/OEM | Accepted |
| Shipping Ways | By sea, by air, or by Express (DHL,UPS FEDEX,TNT, etc.) |
| Payment Terms | T/T, Western Union, MoneyGram, Paypal or L/C |
| Package | Carton, or customize according to your requirements |
| Certification | CE, RoHS, ISO |
Single channel Inductive Vehicle Loop Detector SFLP102:
Our Services
1. Provide free technical training, guidance and information of our products and accessories.
2. Our technical staff could instruct our customers on the installation of barrier gates, tripod turnstiles, flap barriers, swing barriers, full height turnstiles, parking barrier lock and etc, and deal with technical and quality issues.
3. We guarantee more than 10 years’ service life of our products with 1 years’ warranty and life maintenance.
4. Once receive the customer requirements and complaints, we will response within 24 hours.
5. Free maintenance and replacement will be provided if defects result from quality failure of our product.
6. Our company will provide technical services by phone, fax, e-mail, skype etc., please refer to the contact details.
7. Our company will implement the contract strictly; deliver the products to location specified by our customers for free in accordance with the mode of transportation.
8. Our company will provide perfect after-sale services and technical support.
Company Information
Sunfre International Industrial (Shenzhen) Co., Ltd. is a high-tech enterprise in Shenzhen China, headquartered in Hong Kong, and now a leader in greater China in the research and development, manufacture and distribution of intelligent security and protection products and service. Sunfre products series mainly include automatic barrier gates, car parking facilities and systems, turnstiles(tripod turnstile, swing turnstile, wing turnstile, arm drop turnstile), electrical folding gate, remote control parking lot barrier, sliding gate operators, swing gate openers series products etc. Products covers a wide range series and models, and with comprehensive functions and high quality, can meet kinds of customers requirements. Sunfre Products passed the CE certification and ROHS certification, and welcome by all our customers.
Sunfre series products with its innovative design, abundant and comprehensive functions, advanced production technology, steady and trustness quality, on time delivery and thorough service win the domestic and overseas customers highly recognized. Sunfre products sell to more than 50 countries all over the world, mainly in east and south Asia, Euro, north America and south America, Oceania or other areas.
Sunfre apply itself to provide our customers with constant innovative and high quality products, services and solutions, also provides ODM,OEM service to the related products, in order to create long term and steady customer satisfaction and value for our customers.
FAQ
Lead Time: less than 15 days if not custom products
Warranty time: 12 month to 24 month accordingly
Welcome to inquire at your convenience~
Email: julia at sunfre.com / sales02 at sunfre.com
Skype: sunfre.sales02
Mob./Whatsapp: +86 13590280984
...
