2022 Best selling 180 degree rotating rigid joint wireless endoscope endoscopy small camera
- Category: Surveillance Products >>>
- Supplier: Shenzhen Hivibel Technology Co. Limited
Share on (60628484636):
Product Overview
Description
Products Description
H5807BL 2 way 180° Rotation Rigid Articulating Borescope Inspection Camera
This 2-way 180° rotation rigid articulating inspection camera video borescope allows you to view and inspect hard to reach area.
It has 5.8mm lens diameter with 6 adjustable LED lights for dark area inspection. Equipped with IP67 waterproof camera with 63cm rigid stainless steel tube that extends the area of inspection.
FEATURES
Articulating camera head adjusts up to 180 viewing angle
Allows for easy surveying of small, hard-to-reach places
Mini 5.8mm water-proof camera with 63cm rigid extended stainless steel tub
Increase visibility with 3×zoom capability
Manufactured and tested IP67 waterproof standard
3.5''TFT-LCD detachable/mountable monitor recording/still image capture, buil-in rechargeable li-battery, Video recording
capacity, supports up to 32G microSD card
6 white leds for night vision, adjustable brightness on lens-mounted LED light
Lightweight, handheld design, flexible and convenient to use
Features of Articulating Inspection Camera :
Rechargeable li-battery in both camera handle and monitor
Package with aluminium tool case
This 2-way 180° rotation rigid articulating inspection camera video borescope allows you to view and inspect hard to reach area.
It has 5.8mm lens diameter with 6 adjustable LED lights for dark area inspection. Equipped with IP67 waterproof camera with 63cm rigid stainless steel tube that extends the area of inspection.
FEATURES
Articulating camera head adjusts up to 180 viewing angle
Allows for easy surveying of small, hard-to-reach places
Mini 5.8mm water-proof camera with 63cm rigid extended stainless steel tub
Increase visibility with 3×zoom capability
Manufactured and tested IP67 waterproof standard
3.5''TFT-LCD detachable/mountable monitor recording/still image capture, buil-in rechargeable li-battery, Video recording
capacity, supports up to 32G microSD card
6 white leds for night vision, adjustable brightness on lens-mounted LED light
Lightweight, handheld design, flexible and convenient to use
Features of Articulating Inspection Camera :
Rechargeable li-battery in both camera handle and monitor
Package with aluminium tool case
SPECIFICATIONS
MODEL | H5807BL | |
CAMERA | Image Sensor | CMOS |
Diam. of Insertion Tube | 5.8mm | |
Effective Pixels | 704X576(PAL) 712X488(NTSC) | |
Field of View(FOV) | 50° | |
Bending Angele | 180° | |
Weight | 375g | |
Focus Distance | 3cm(approx) | |
Depth of Field(DOF) | 30cm(approx) | |
Illuminative Distance | 0.5m(6LEDs) | |
Water Proof | IP67 | |
Lowest Illumination | 0Lux | |
Transmission Distance | 10m(Max.) | |
Transmitting Frequency | 2468MHz | |
Video Out | 1p-pv@75ohm | |
Power | 5V1.5A | |
MONITOR | Curren Consumption | 260mA |
Work Time | 6 hours | |
Product Dimension | 113mmX45mmX43mm (Active area) | |
Screen Size | 3.5'' TFT-LCD | |
Display Resolution | 320(R.G.B.)X240dot | |
Video Format | NTSC /PAL | |
Modulation Mode | FM | |
Receive Sensitivity | -85dBm (module) | |
Built-in Li-Battery Capacity | 1100MAH/3.7V | |
Charge Time | 3 hours | |
Work Time | 3 hours | |
Consumption Current | 500MA(MAX.) | |
Menory | Micro SD Card | |
Picture Format | .JPG | |
Video Format | .AVI | |
Picture/Video Resolution | 640X480 | |
Frame Rate | 30Frame/S | |
Operation Tempreature | 0~+45°C | |
Storage Temperature | -20~+60°C |
APPLICATIONS
Cavity wall inspection, wall tie and dry rot inspection, pest control inspection, pipe inspection, Cavity wall inspection, wall
tie and dry rot inspection, pipe inspection, auto repair detection, machinery overhaul, maritime detection, search and Rescue,
customs inspection, anti-terrorist demolition blasting, laboratory observation, archeological exploration.
tie and dry rot inspection, pipe inspection, auto repair detection, machinery overhaul, maritime detection, search and Rescue,
customs inspection, anti-terrorist demolition blasting, laboratory observation, archeological exploration.
Packaging & Shipping
Shipping way could be chosen according to customers requirements, courier delivery, air cargo, sea cargo or designated freight
forwarding . We will coordinate with every delivery from factory to destination, and keep reporting the status of transportation.
forwarding . We will coordinate with every delivery from factory to destination, and keep reporting the status of transportation.
Notice: Our payment terms will differ by countries and regions, please contact our sales person to define the final payment terms.
Price
The prices listed are the reference prices. We will provide the competitive factory price according to your order quantity based
on EXW or FOB or DDP. We can also quote the best freight cost by courier/air/land/ forwarder for your reference.
MOQ
We don't have MOQ except for OEM/ODM/customized products. The prices vary depending on order quantity.
Order Process & Payment term
Alibaba online order is ready for the total value including freight cost less than 5000USD:
Step 1: Please provide your email and contact information to us.
Step 2: We will make a draft quotation for your confirmation.
Step 3: You make payment after confirmation.
For the order value above 5000USD, we only can provide you offline order:
Step 1: Please you place order to us by email or message.
Step 2: We send Proforma Invoice to you for your confirmation.
Step 3: You make payment after confirmation.
Payment term :T/T,Western Union(only for payment less than 2000USD)
Packing
All the inspection camera kit is standard packed with tool case. Special requirements should be mentioned in order.
Shipping
Shipping way could be chosen according to customer requirements, courier delivery, air cargo, sea cargo or designated freight forwarding . We will coordinate with every delivery from factory to destination, and keep reporting the status of transportation.
Production Time
Usually our products are in stock for order less than 10units, but if one of our product is out of stock, the production time for standard products will be from 3-15days according to the order quantity. For OEM/ ODM/customized products, the production time will be 20-45days different according to the degree of difficulty or easiness.
The prices listed are the reference prices. We will provide the competitive factory price according to your order quantity based
on EXW or FOB or DDP. We can also quote the best freight cost by courier/air/land/ forwarder for your reference.
MOQ
We don't have MOQ except for OEM/ODM/customized products. The prices vary depending on order quantity.
Order Process & Payment term
Alibaba online order is ready for the total value including freight cost less than 5000USD:
Step 1: Please provide your email and contact information to us.
Step 2: We will make a draft quotation for your confirmation.
Step 3: You make payment after confirmation.
For the order value above 5000USD, we only can provide you offline order:
Step 1: Please you place order to us by email or message.
Step 2: We send Proforma Invoice to you for your confirmation.
Step 3: You make payment after confirmation.
Payment term :T/T,Western Union(only for payment less than 2000USD)
Packing
All the inspection camera kit is standard packed with tool case. Special requirements should be mentioned in order.
Shipping
Shipping way could be chosen according to customer requirements, courier delivery, air cargo, sea cargo or designated freight forwarding . We will coordinate with every delivery from factory to destination, and keep reporting the status of transportation.
Production Time
Usually our products are in stock for order less than 10units, but if one of our product is out of stock, the production time for standard products will be from 3-15days according to the order quantity. For OEM/ ODM/customized products, the production time will be 20-45days different according to the degree of difficulty or easiness.
