SONLY's "U-TS"series with clamping force ranges from 98ton to 3400ton injection molding machine. besides, we also have special machine for PVC, PET, Variable Pump, clear double color, servo-motor machine,high speed injection machine. Following specification is U98TS :

Main Features

One.The Lock Section
1.Arch template, effectively protects the mould, especially suitable for big template with small mold.
2.The electric ruler is installed on the crosshead, the position is more precise.
3.The front connecting rod uses connected structure, increases the rod strength, and easy for assembly
4.The connected tail-board stills itself with big lock shaft, improves tail-board strength, and ensures zero abrasion of the tail-board, easy for maintenance.
5.Connected movable plate, improves its rigidity and reduces deformation
6.Connected thrust bearing, improves its strength and stills itself with small lock shaft, ensures zero abrasion.
7.Arch template fully complies with mechanical property, largely improves template strength.
8.More reasonable toggle design, speeds and stabilizes mold opening and closing.
9.Adjustable movable plate mounting plate, makes the installation easier.
10.Mixed design of T-shape groove and die hole, increases universality of the mold.

Two.The Injection Section.
1.Bridge type support, improves injection smoothness.
2.Longer length-diameter ratio screw design, improves plasticizing effect.
3.Double seal structure, ensures no oil leakage.
4.Withhold type press plate, easy for debugging and assembly.
5.Bijection structure, improves stability.

Certifications
Detailed Images

Clamping Unit

• Finite element analysis on structure, the mould board is more logical, stronger and higher fatigue resistance.
• Low pressure protection function greatly prolongs the service life of the mould.
• High precision electron meter is used to control position, the control precision is 0.1 mm.
• Mechanical, electric and hydraulic (optional) safety protection are equipped

Injection Unit

• Superior and efficient separating screw and high mixing screw increase the range of material used, and guarantee molten material to be uniform and stable.

Controller

• Fuzzy temperature control is use. High and low temperature deviation alarm and thermocouple disconnection inspection functions are available.
• Function to prevent cold material start-up.
• Times of forming can be matched with automatic stop function for convenient production management.
• Computer controlled automatic lubrication devices.
• Automatic mould adjustion function.

Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.
