Product Overview

Description


Product Description

Standard

IEC 60502: Power cables with extruded insulation and their accessories for rated voltages from 1 kV (Um=1.2 kV) up to 30 kV (Um=36 kV) - Part 1: Cables for rated voltages of 1 kV (Um=1.2 kV) and 3 kV (Um=3.6 kV)

Application

This copper conductor PVC insulation and sheath power cable is used in underground power transmission lines of rated voltage 600/1000V and below. Besides, flame retardant and fire resistant xlpe insulated copper cable is also available.

Product Details

1) Conductor: stranded plain copper

2) Sectional area: 25~95 mm2

3) Insulation: PVC

4) No. of cores: 1

5) Outer sheath: PVC

6) Cable size

\t
Area
\t
Insulation thick.
(mm)
\t
Sheath thick.
(mm)
\t
Overall dia.
(mm)
\t
Approx. weight
(kg/km)
\t
Max. DC Resistance at 20 degree
(ohm/km)
\t
25
\t
1.2
\t
1.4
\t
11.0
\t
309
\t
0.727
\t
35
\t
1.2
\t
1.4
\t
12.0
\t
409
\t
0.524
\t
50
\t
1.4
\t
1.4
\t
13.2
\t
560
\t
0.387
\t
70
\t
1.4
\t
1.4
\t
15.1
\t
764
\t
0.268
\t
95
\t
1.6
\t
1.5
\t
16.9
\t
1016
\t
0.193
Certifications
Factory & Equipment
Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Provide one-step cable solution according to customer's requirements

After-Sales Service

* Provide installation guidance.

* Engineers available to service overseas.

Packing & Delivery
\t
Packaging
\t
Size
\t
50cm (L) * 50cm (W) * 20cm (H) and below
\t
Weight
\t
30 kg and below
\t



Packaging Details
\t
1) Usually used for cables with a diameter less than 10mm.
2) 100 meters (or other length required by the customer) per roll.
3) Polyethylene film or tape is used for the outer packaging.
\t
Packaging
\t
Size
\t
180cm (L) * 110cm (W) * 180cm (H)
\t
Weight
\t
3 T
\t



Packaging Details
\t
1) Wood or wood drum (110cm and smaller size) or steel-wood drum (over 110cm) is used for packaging the cables with a diameter of 10mm and above.
2) Packing length as per customer's requirements
