high quality Automotive Rotary Switch Assembly Machine

Product Overview

Description

Automotive Rotary Switch Assembly Machine

Introduction

1. This automatic rotary switch assembly machine manufactured to implement from components and parts loading, feeding, locating, inserting, cutting, and pressing, inspecting to final unloading.

2. Designed with excellent compatibility that could be a solution for a series of rotary switch in different number of terminal

3. Custom-design vibratory bowl feeders keep terminal and plastic housing supply in time separately

4. Well performed control system consist of PLC and human machine interface touch panel ensure equipment easy to access and operate

5. Providing after sale service both domestic and overseas



Functional Description



1. Terminal loading and feeding.

Terminal with silver contact riveted are conveyed through vibratory bowl and linear vibratory feeder enter into workstation alignment

2. Plastic housing loading and feeding

A custom selector is mounted on vibratory bowl ensure the plastic housing conveying to the designated position and await assemble

3. Terminal insertion and cutting

Terminal will be inserted to the plastic housing through a special press and insertion mechanism. After insertion, the special made cutting device will perform cutting process

4. Sorting and unloading

Conductivity testing and CCD visual inspection system perform the sorting mechanism and select reject from accept and unloaded separately





Features

1. With the user-friendly human machine interface (HMI) and touch control panel, easy to operate and also protect the safe of the operator
2. The Pneumatic component or parts are introduced with branded Air TAC, SMC, Festo that enables the process more stable and accurate;
3. All of automatic assembly motions in entire machine are designed with continuous interlock function, the machine will alert & shutdown in an automatic way if any abnormal occurred;
4. The machine frame employs electrostatic spraying & paint-drying processes with the purpose to anti-rust;















WHY WORKS WITH DINGLI TECH
1. Most famous companies like Tyco, Amphenol, Molex,ZTE, CTZ, Defond, SOKEN, HUAGENG choose to cooperate with Dingli Tech because we have more flexible solution, and more mature technology in automatic assembly solution;

2. A professional team with more than 10 year’s experience in assembly engineering design will guarantee a high efficient automated assembly solution for customer’s product in a way of scientific design and engineering procedures;

3. Dingli Tech created a practical method to verify the assembly process of the designed automated assembly machines to answer for massive assembly & processing demand, mostly, a cost-effective solution will be generated and provided to our customer to improve assembly quality and increase productivity;

4. The transaction term of leading time will be reached in time and on time, which shall thanks to our manufacturing team that boost around more than 80 staffs, skilled mechanical and electricla workers ensure the quality of automated assembly machine;

5. Services: Engineers with passports will be available to perform on-site support in customer’s site to install, commission the automated assembly machine and train operators from customer;

Third party and agent service are also available depending on our agent in some regions.

6. Original Branded Components
All of the components and elements for the automated assembly machine such as pneumatic component
The original source for these branded components and parts can be guarantee through our purchasing department, fake or copied parts are not allowed to be introduced for the machines.

7.Available to concept, design, manufacture the single integral assembly machine or the assembly lines such as straight-line, or U-shaped assembly, which is more ergonomic and advanced.





Technical Specification



Machine Name	Automatic Rotary Switch Assembly Machine
Machine Model	DL-SA-119
Overall Dimension	Approx.  1200*780*750mm (variables due to custom design)
Gross Weight	Approx. 185kg
Air Pressure	>0.6Mpa
Productivity	35pcs/min.
Voltage/Frequency	110-240V   50/60Hz
