2cavity Semi Automatic PET Bottle Blowing Machine / BLower

Product Overview

Description

2cavity Semi-Automatic PET Bottle Blowing Machine / BLower





Model	DEG-3L  (One Blower & One Heater)	DEG-3L-II (Two Blower & One Heater)
Clamping Force	100KN	100KN
Clamping Stroke	160 MM	160 MM
Max. Stretching Stroke	360MM	360MM
Number of Cavities	2 Cavity	2 Cavity
Theoretical Output	900 BPH(500ml)	1800 BPH(500ml)
Max. Mold Thickness	300MM	300MM
Voltage Standard	380v/3PH/50Hz or special order	380v/3PH/50Hz or special order
Number of Heating Zone	4 Sections	4 Sections
Total Power (Full Loaded)	10KW	15KW
Max. Container Volume	2L	2L
Neck Diameter Range	18-120mm	18-120mm
Max. Container Diameter	360mm	360mm
Max. Container Height	380mm	380mm
Low Air compressor	10Bar	10Bar
High Air compressor	30-40Bar	30-40Bar
Blow molding machine	1450*600*1700mm	1450*600*1700mm*2
Preform Heater	1800*700*1400mm	2100*700*1400mm
Net Weight	850kgs	1300kgs









1> Q: Are you a factory or trading company?

A: We are factory.



2> Q: Where is your factory located?

A: Our factory located in Taizhou City, Huangyan Area - “Town of Mold” in China, near Shanghai and Ningbo port. 3hours by train from Shanghai, 2hours by air from Guangzhou.



3> Q: How about quality control in your factory?

A: “ Quality is the key point, do what customers needs”

Degree company focus on quality, pay great attention to quality control from beginning to the end.



4> Q: How about guarantee for machines and moulds?

A: For machines offer one year guarantee. For molds we offer one year or 3million short guarantee, based on which comes first.



5> Q: Is there complete machine include mould and other accessories ?
A: Yes ,what we are provide is the complete system .



6> Q: What is the language of the PLC and touch panel?
A: Don’t worry, we will translate the language in English, make sure you will have a easy operation .



7> Q: Can you help us with the shipment of this machine ?
A: Yes , with honor ,we have our special shipment company which already cooperate for long time, you can contact us for the freight , we will give you the best price we can. Also you can ask your own shipping forwarder, we help you done other things. Customer satisfy, is our target.
