LV 3 Core Rubber Insulation Submersible Flat Cable
LV 3 Core Rubber Insulation Submersible Flat Cable
LV 3 Core Rubber Insulation Submersible Flat Cable
LV 3 Core Rubber Insulation Submersible Flat Cable
LV 3 Core Rubber Insulation Submersible Flat Cable

LV 3 Core Rubber Insulation Submersible Flat Cable

Share on (60646083994):


Price:

Quantity:


Product Overview

Description


Product Description

Standard

IEC 60245-4: Rubber insulated cables - Rated voltages up to and including 450/750V - Part 4: Cords and flexible cables

Application

This 3 core rubber insulation submersible flat cable is used as the power supply cable of submersible pumps of rated voltage 500V and below.

Product Details

1) Conductor: class 6 plain copper

2) Sectional area: 2.5~35 mm2

3) Insulation: rubber

4) No. of cores: 3

5) Outer sheath: rubber

6) Cable size

\t
Cores x Area
(No. x mm2)
\t
Insulation
(mm)
\t
Sheath
(mm)
\t
Cable size
(mm)
\t
Approx. weight
(kg/km)
\t
DC resistance at 20 degree
(ohm/km)
\t
3 x 2.5
\t
0.8
\t
1.0
\t
18.0 x 6.0
\t
195
\t
7.98
\t
3 x 4
\t
0.8
\t
1.2
\t
19.0 x 7.0
\t
265
\t
4.95
\t
3 x 6
\t
0.8
\t
1.2
\t
22.0 x 7.8
\t
360
\t
3.30
\t
3 x 10
\t
1.0
\t
1.4
\t
26.2 x 9.3
\t
560
\t
1.91
\t
3 x 16
\t
1.0
\t
1.5
\t
30.0 x 10.7
\t
765
\t
1.21
\t
3 x 25
\t
1.2
\t
1.6
\t
36.1 x 13.0
\t
1220
\t
0.780
\t
3 x 35
\t
1.2
\t
1.7
\t
40.8 x 14.5
\t
1580
\t
0.554
Certifications
Factory & Equipment
Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Provide one-step cable solution according to customer's requirements

After-Sales Service

* Provide installation guidance.

* Engineers available to service overseas.

Packing & Delivery
\t
Packaging
\t
Size
\t
50cm (L) * 50cm (W) * 20cm (H) and below
\t
Weight
\t
30 kg and below
\t



Packaging Details
\t
1) Usually used for cables with a diameter less than 10mm.
2) 100 meters (or other length required by the customer) per roll.
3) Polyethylene film or tape is used for the outer packaging.
\t
Packaging
\t
Size
\t
180cm (L) * 110cm (W) * 180cm (H)
\t
Weight
\t
3 T
\t



Packaging Details
\t
1) Wood or wood drum (110cm and smaller size) or steel-wood drum (over 110cm) is used for packaging the cables with a diameter of 10mm and above.
2) Packing length as per customer's requirements
