Honeywell STR Remote Diaphragm Seals Unit Transmitters
Introduction
Part of the SmartLine® family of products, the STR800 is a
series of high performance pressure transmitters hydraulically
matched and optimized with a complete set of remote
diaphragm seals. Utilizing the same high performance sensor
technology of the ST 800 product line Honeywell has
optimized the mechanical and hydraulic designs in order to
minimize the typical effects of temperature on remote seal
systems.
Typical Diaphragm Seal applications
• High Process Temperatures
• Viscous or Suspended Solids
• Highly Corrosive Process Materials
• Sanitary Applications
• Applications with Hydrogen Permeation Possibilities
• Level Applications with Maintenance Intensive Wet
Legs
• Applications requiring remote Transmitter Mounting
• Tank Applications with Density or Interface
Measurements
Communications/Output Options:
• Honeywell Digitally Enhanced (DE)
• HART ®
(version 7.0)
• FOUNDATION™ Fieldbus
All transmitters are available with the above listed
communications protocol
| Model | URL | LRL | Min Span | Maximum Turndown Ratio | Reference Accuracy1,2 (% Span) |
| STR82D | 400 in H2O (1000 mbar) | -400 in H2O (-1000 mbar) | 4 in H2O (10 mbar) | 100:1 | 0.0375 |
| STR83D | 100 psid (7.0 bar) | -100 psi (-7.0 bar) | 1 in psi (0.07 bar) | 100:1 | 0.0375 |
| STR84D | 500 psi (35 bar) | -14.7 (-1.0 bar) | 5 psi (0.35 bar) | 100:1 | 0.0375 |
| STR87D | 3000 psi (210 bar) | -14.7 psi (-1.0 bar) | 30 psi (2.1 bar) | 100:1 | 0.0375 |
| STR84A | 500 psia (35 bara) | 0 psia (0 bara) | 5 psia (0.35 bara) | 100:1 | 0.0375 |
